Aegis Power Systems, Inc. products

The 1PH400 is a 400Hz VME power supply with a SWaP optimized design. With its 6U form factor and 5HP size, this single slot filtered AC-DC power supply converter card fits a lot of power into a small space.

This 115/220Vac power supply has the option for 3 or 4 outputs in varying voltages (+5Vdc, 3.3Vdc, +12Vdc, and -12Vdc). This 400Hz single slot VME power card meets current industry standards for SWaP optimized design. This single phase power solution is best suited for industrial and military VME applications and is designed to meet portions of Mil-Std-704F input requirements, MIL-STD-810F vibration and shock requirements, and MIL-STD-461E EMI requirements. Features include 6U form factor, wedgelock conduction cooling, high efficiency (86% with 220Vac input), low weight (3.5 lbs), and high power (up to 375W).

This ruggedized military Commercial Off the Shelf (COTS) power supply operates from a 3-Phase 208Vac input. The single 9000W output capability is the power supply solution for military COTS applications. It is designed to meet the environmental requirements of IL-STD-810F and the EMI requirements of MIL-STD461F. In comparison to other power supplies using conventional technology, this package provides its users with higher efficiency (83% typical), less weight and higher power output. This power supply is designed to power military 28Vdc electronic equipment including communications and vehicular onboard power.

This rugged PSU is designed for heavy-duty ground vehicle applications requiring 3-phase AC input and 270Vdc output. Providing 11kW of power, this power supply yields high power for military equipment shore power. Enclosed in an IP56 water resistant housing and designed to meet MIL-STD-461F, MIL-STD-1275E, and MIL-STD-810F, this unit is made for durability in harsh environments.

The BG2802 is an enclosed DC-DC power converter with a single 28Vdc output. This military COTS solution is designed to meet applicable portions of Mil-Std-704A/E/F input requirements, MIL-STD-810F vibration and shock requirements, and MIL-STD-461E EMI requirements. This conduction cooled DC-DC power converter provides users with 80% efficiency, low weight (3 lbs), and 290W power (surge). Designed for airborne environments up to 50,000 ft altitude.

This open frame filtered DC-DC power converter has multiple outputs available with N+1 redundancy. This COTS power solution works well for many defense applications and is designed to meet applicable portions MIL-STD-810F vibration and shock, and MIL-STD-461 surface ship applications EMI requirements. When compared to VME power supplies using conventional technology, this chassis mount forced air cooled AC-DC power supply converter provides users with higher efficiency (81%), lower weight (6.3 lbs), and higher power (up to 311W, N+1 redundant).

This 6U AC-DC power supply  offer rugged design in compact space. This unit has dual outputs available of +5Vdc at 200W and +12Vdc at 300W, for a total of 500W output. Best for military, telecom, and industrial applications, this filtered power supply solution is designed to meet applicable portions of Mil-Std-704F input requirements, MIL-STD-810F vibration and shock requirements, and MIL-STD-461E EMI requirements. This SWaP optimized power converter provides users with high efficiency (85% with 220Vac input), low weight (3.5 lbs), and high power (up to 500W).

This dual slot AC-DC power supply is designed for use in VME systems. This single phase power converter module yields 375W power output at 70ËšC and is designed to meet applicable portions of Mil-Std-704F input requirements, MIL-STD-810F vibration and shock requirements, and MIL-STD-461E EMI requirements. This filtered power card is cooled via customer-supplied air fan across the attached cooling fins.

This single phase AC-DC power supply provides 85-264Vac input to 28Vdc output with 310 watts and built-in EMI filtering. This rugged slide-in power supply offers +12V and +3.3V (Aux) outputs and has been developed in alignment with the Sensor Open Systems Architecture™ (SOSA) technical standard for use in modular open systems architectures for sensor management.

This single slot 270Vdc VPX power card offers six outputs at 650W maximum power and includes internal filtering. This standard PSU is available as a COTS military power supply solution designed to meet applicable portions of MIL-STD-810F vibration and shock and MIL-STD-461E EMI requirements. The very thin VPX2703UC provides users with higher efficiency (up to 93%), and higher power (up to 650W), yielding a SWaP optmizied approach to power. It also has alignment keys that offer keying options when using multiple power supplies in one chassis.
