BYD Company Limited products

Overview - Fe battery is a core technology of BYD. It has excellent safety, high energy density, long service time, nice temperature performance, low cost and no pollution, which could help users to save cost and prevent from environmental problems.

To meet the needs of Australian,Janpanese,Europe and the United States markets, BYD has promoted the solutions for 3kW/3kWh household energy storage system depengding on the development and operation for years.The solution has integrated LiFePO4 batteries,PCS, Distributed BMS,monitoring system and other advanced technologies to emphasize the integration of intelligence and overall technical superiorities. Through APP (supporting IOS and Android systems), it can make a remote monitoring,which has high reliablity, safety ,efficiency, environment-friendly and other advantages,and it`s of small size, light weight,easy to install and maintenance.

Integrated DESS is a distributed energy storage system that integrates energy conversion system (PCS), energy batteries and BMS, photovoltaic charger with little-volume and compact-structure. Integrated DESS is single-phase AC output; applicable for the occasions that electrical load is relatively small.

20KW/40KWh Energy Storage Cabinet adopts steel 42U standard cabinet (the bottom surface is 600mm×1200mm)as the body, consists of 38KW on-grid PCS modules, 20KW PV charger module and 40KWh lithium iron phosphate battery modules with high performance and high safety, applicable to the occasions of energy storage, power regulation and frequency modulation; Many machines can be in parallel to realize capacity expansion; it can form into micro-grid system with other generating equipment, coordinate and match the output power of each generating device according to the load demand.

The conversion efficiency of BSG500KTL-A Non-isolated PV Grid-tied Inverter is up to 98.5% with IP54 protection grade design, which is installed indoors, outdoors or containers, applicable to large-medium PV station, with the advantages of high conversion efficiency, high generation, reliable operation and strong stability.

The conversion efficiency of BEG630KTL-A Non-isolated PV Grid-tied Inverter is up to 98.5% with IP54 protection grade design, which is installed indoors, outdoors or containers, applicable to large-medium PV station, with the advantages of high conversion efficiency, high generation, reliable operation and strong stability.

Modularity inverter can realize the paralleled operation of 1-8 independent 125KW inverter module units. The whole set of equipment shares one set of control unit in order to save costs. The new inversion technology design decreases the loss and improves the whole efficiency. Independent inverter module can start in turn, through starting the optimum number of inverter modules, the working time of inverter module can be balanced so as to effectively lengthen the service life of the whole set of equipment. Independent inverter module can be safely cut off through load switch, there is no need to shut down all the machines to maintain and replace the independent module, so it won’t influence the operation of other modules. Humanized touch screen operation interface can be maintained without shut down. Remote monitoring system is adopted to check and modify the system setups, easy to maintain and fast to response

BEM33KTL is modular inverter. It can operate in parallel. New converter technology design would reduce consumption and improve the overall efficiency for BEM33KTL. The inverter also has advantages on high conversion efficiency, fast conversion of full power charging/discharging, wide range of environment working temperature.

The national wind power, solar power, energy storage and transmission demonstration project located in Zhangbei, Hebei Province, is a part of the national “Golden Sun” program and one of the smart grid pilot tests of State Grid Corporation of China (SGCC).The project is cosponsored by the Ministry of Finance, the Ministry of Science and Technology and SGCC with an investment over RMB3.3 billion. Constructed by State Grid Xin Yuan Co., Ltd., this massage utility-scale project combines 100MW of wind power, 50MW of solar power and 20MW of energy storage. BYD’s Iron-Phosphates battery storage system with a capacity of 6MW/36MWh accounts for the majority of the project’s energy storage. The energy storage station aims to achieve wind-solar output smoothing, schedule following, peak shaving and frequency regulation technical difficulties of new energy application inside the utility system.

The project is BYDMobile Demonstartion Energy Storage Project with the advantagesof shorter construction cycle, longer service period, more convenient move, higherreliable, less environment pollution, less wasting of land and other resources，larger military strategy senses, and having a wide market prospect.
