10 products found
CIRCUTOR, S.A. Products
-
Measurement and Control
-
CIRCUTOR - Model CVMK2 - Power Analyzer Mounting Panel
Three-phase power analyzer (balanced and unbalanced) for its assembly on panel or DIN rail mounting with a graphical display. Measuring in 4 ...
-
CIRCUTOR - Model QNA500 - Modular Power Quality Analyzer
Electrical parameter indicator equipment Its design enables the installation of the unit on small panels. It measures voltage, current, frequency and harmonic distortion, depending on the type Fully sealed.Fully programmable alarm relay.Robust and compact.Stores maximum and minimum ...
-
CIRCUTOR - Model QNA400 - Power Quality Analyzers
QNA 412 is a state-of-the-art power quality analyzer certified as a class A device, in compliance with the IEC-61000-4-30 Standard. It takes measurements in compliance with the international standard. In addition to the analysis of the variables related to the quality of supply (voltage, flicker, harmonics, events, etc.), it also acts as a network analyzer and redundant counter, since it can be used to analyse the current signals, power consumed (active ...
-
CIRCUTOR - Model Q20543 - Power Analyzer
QNA-PT is a state-of-the-art power quality analyzer certified as a class A device, in compliance with the IEC-61000-4-30 Standard. It takes measurements in compliance with the international standard. In addition to the analysis of the variables related to the quality of supply (voltage, flicker, harmonics, events, etc.), it also acts as a network analyzer and redundant counter, since it can be used to analyse the current signals, power ...
-
CIRCUTOR - Model CVM-C5 - Power Analyzer Panel
The CVM-C5 is a multifunctional multimeter for 96x96 mm panels with a compact energy log and four-quadrant measurement. Suitable for low-voltage installations in three-phase circuits with three or four wires, two-phase circuits with or without neutral or single-phase ...
-
CIRCUTOR - Model EDS - Energy Manager System
EDS is an energy manager equipped with PowerStudio Embedded and a built-in web and XML server, which enables the user to query any electrical variable by connecting the metering equipment to its RS-485 bus without having to install any software. Thanks to the RS-485 expansion bus, the user can view any variable from the units connected to the bus and can even display information in real time, in table or graphic format (data logger). There are 8 ...
-
Metering
-
CIRWATT - Model B410T - Three-Phase Indirect Connection Meter
CIRCUTOR’s CIRWATT B 410T is a standard three phase indirect connection meter, as a result of all the technological developments which is experiencing the current market. These changes have created new needs and requirements both in terms of more flexible rates, new communications systems and a price ...
-
CIRWATT - Model B502 - Three-Phase Energy Meters
CIRWATT B, Three-phase energy meters (Measuring, load profiling, multi-configurable billling calendar) AMR Meters There are installations in which due to high energy consumption or generation, the accuracy of the meter to be installed is a key factor to consider. CIRCUTOR offers the best option to measure large amounts of energy. CIRWATTB 502 is a high accuracy meter, with four quadrants measurements and different communications and expansion ...
-
Protection and Control
-
Model WGC - Earth Leakage Relays
This new range presents a series of improvements above all in the installation of equipment in switchboards. Along with the usual installation fixtures, we add the possibility of doing it with a DIN rail by means of an accessory, which would facilitate its installation. The WGC series earth leakage transformers have a greater immunity to transitory type current peaks that usually cause differential protection triggers. The earth leakage transformers of ...
-
Model WGS - Earth Leakage Transformers
The earth leakage transformers of the WG Series have been designed to work with the relays of the WG Series. The sensitivity (trigger current) of the transformer-relay set is established by the associated ...
