ENO Energy GmbH products

General: Rated Power: 5.4 - 6.0 MW. Cut-in wind speed: 3 m/s. Rated wind speed: 12.5 m/s. Cut-out wind speed: 25 m/s. Tilt angle: 6°.

General: Rated Power: 5.6 - 6.0 MW. Cut-in wind speed: 3 m/s. Rated wind speed: 13 m/s. Cut-out wind speed: 25 m/s. Tilt angle: 6°.

Reliability, performance and yield are the top priorities for low wind regions. The 66.8-metre-long rotor blades of the eno 136 represent an optimised flow of air and the aerodynamic high-performance design ensures maximum yields and economy of the wind turbine in low wind regions. With 14612m² of coated rotor area, 4,500 Kilowatts of rated output, the eno live.train solution and the advanced eno split.drive, the eno 136 presents an sophisticated system produced in Germany. Thanks to the combination of innovative solutions with excellent technical availability, the eno 136 is a high-quality investment in the future.

The latest technology for the greatest added value. The optimised rotor aerodynamics and the advanced carbon fibre technology of the eno126 ensure new benchmarks when it comes to economy and weight reduction. Highly innovative design solutions, paired with the robust machine design, make the eno126 a safe long-term investment in a new generation of wind power stations.  12,500 m² of painted rotor surface make them ideal for inland sites. Up to 4,800 kilowatt nominal power, paired with an increased turbine classification, make the eno126 one of the most economic solutions in the wind farm.

High economic efficiency in the wind farm. The eno114 also guarantees maximum farm yields in locations with increased environmental turbulence. 4,800 kilowatts of nominal power make the machines the most powerful On-Shore turbines in the 4-megawatt class and, with a perfect balance between robust, conservative machine design and highly innovative detailed solutions, the eno114 achieves an unmatched packing density.

The latest feed-in technology and robust turbine construction. The eno 100 stands for highest efficiency of turbine design. Based on the tried and tested platform eno 92, the wind turbine has the ideal combination of compactness, solid machine construction and increased yield with a rotor diameter of 100 metres and thus around 18 percent more rotor surface area. The design of the eno 100 takes into account the maximum utilisation of low-wind locations in particular. Our own developed controls and the modern full-scale converter technology guarantee sure operation in demanding networks.

Dependable yields even at highest requirements are ensured by the eno 82 due to its highly innovative full-power converter and control technology combined with a robust, dependable machine design. Flexible hub heights starting from 58.6 metres allow for a wide range of applications. Because of its compact dimensions and its optimal component weights, the eno 82 wind turbine is the ideal choice for site specific logistically challenging projects.

With its flexible hub heights up to 123 metres and a swept rotor area of 6,764 m even at low wind speed sites the eno 92 provides for profitable yields. Optimal compatibility in all grids is ensured by the eno 92 due to its highly innovative full-power converter technology.The generator design exhibits a consequential strict avoidance of all rare earths.

Highest efficiency – This is what construction and design of the eno 100 stands for. Based on the established platform of eno 92 added by a rotor diameter of 100 meters and with this about 18 % more swept area, the eno 100 combines optimally compactness, solid engineering and much increased yields. The design of eno 100 is specialy developed to maximize the exploitation of low wind sites. The special control and the modern fully rated converter technology guarantee a safe operation in challenging grids.

The maximum yield of wind farm is ensured by theeno 114, even at sites featuring higher ambient turbulence. 3,500 kWrated power output enables the turbine to be the most powerfulonshore turbine within the 3 MW class. With a perfect balance betweenrobust, conservative machine design and high level innovativedetails, the eno 114 reaches an unsurpassed wind park packing densityand maximum yields for the wind farm.
