Eway Energy Technology (WUHAN) Co., Ltd. products

Introduce the LIFEP04 PowerWall battery for residential energy storagea fashionable home energy storage solution. Thebattery is equipped with Superior quality smart BMS tomonitorthe battery and multiple protection. The UNIV-PowerWallseries lithium battery allows parallel connection to enhance capacity, and can easily monitor its working conditions by uplinkand optional bluetooth. The extraordinarycompatibility of it with the extensive inverter brand ensures seamless integration into your energy system. Selet the UNIV-PowerWall series batterytoensure a reliable and continuous power supplyultimate energydemand selection.

Working Temperature : Discharge Charge : -20 C I0+6OC Ot: to +50 C. Efficiency : >97%. IP rating : IP54. DOD : 90%. Cooling Type : Natural. Communication : CAN.RS485. Warranty : 10 years. Design Life : 15+ Years (25Vmr). Cycle Life : 2*8000@25 C . 80%DOD. Safely : CE/TUV/CellUL1973.

Our integrated Battery Energy Storage Systems provide a mature turnkey solution for commercial & industrial clients seeking reliable backup power & optimized energy management.The systems package lithium-ion battery banks, bi-directional inverters, auxiliary cooling components, and fire suppressionin frastructure together within robust outdoor enclosures.Through proprietary intelligent battery management and advanced thermal control, our BESS achieves excellent safety, performance and lifespan. Customizable control programs enable applications like peak shaving, self- consumption of on-site generation and demand chargereduction. Equipped with scalable storage and discharge capabilities, the systems ensure continuous power for critical equipment and processes. Select models also facilitate integration of photovoltaics.

Total Energy 14.3kWh Nominal Voltage 51.2Vd.c Voltage Range 46.4~57.6Vd.c. Rated Capacity 280Ah. "Recommend Charge. Discharge Current" 146A. Weight 140kg. Dimension（WHD） 620*950*380 mm. Working Temperature Discharge -20℃ to +60℃. Working Temperature Charge 0℃ to +50℃. Efficiency >95%. IP Rating IP55. DOD 90%. Cooling Type Natural. Communication CAN,RS485. Warranty 10 Years. Design Life 15+ Years (25℃/77T). Cycle Life ≥8000@25℃, 80%DOD. Safety CE/Cell UL 1973.

BATTERY PARAMETERS; Total Energy (kWh)7.68. Useable Energy (kWh)7.22. Nominal Voltoge (Vd.c)512. Voltage Range (Vd.c)44.8-57.6. Rated Capacity (Ah)150. Recommend Current (A}Charge75. Discharge75. Peok Charge Current (A)W. Peak Discharge Current (A\101 - 110A @ 1 hour 111 - 250A @ 10 sec. Recommend Using DOD90%. Dimension (W "H* D) (mm)440-660-155. Weight (KG)62.
