HITEMA INTERNATIONAL S.R.L. products

Standard Configuration: Compressors: Scroll. Condenser: Air-Cooled with integrated and optimized Free-Cooling coils, with copper tubes and aluminum finned core. Evaporator: Brazed plate (SBSF-OPT.095÷SBSF-OPT.120) or Shell & Tube (SBSF-OPT.145÷SBSF-OPT.720). Expansion Valve: Thermostatic (SBSF-OPT.095÷SBSF-OPT.430) or Electronic (SBSF-OPT.470÷SBSF-OPT.720). Fans: AC axial. Protection Rating: IP54. Refrigerant: R410A, R454B; R32. Cooling Capacity Range 99kW ÷ 706kW.

SBS-HP SERIES consists of a reversible air-cooled heat pump designed to assicurate an high performance also in case of low ambient temperature, down to -20°C. These units are designed for applications that require reliability, continuity of operation, high performance, reduced management costs and carbon dioxide emissions. This series is composed by three basic models that can by hydraulically an electrically compose to satisfy all final user demands. This simplify maintenance/repair operations (performed only in the damaged module) and the already built installation can be increased in capacity in case of modification of the energy demand. In the event of any malfunction, each module can be easily isolated from the others, which can continue to operate while the faulty module is repaired, so that costly production downtime can be avoided.

HBS SERIES consists of a reversible air-cooled heat pump designed to ensure an high performance also in case of low ambient temperature, down to -10°C. These units are designed for applications that require reliability, continuity of operation and guarantee minimum consumption and high energy savings.

HNR SERIES consists of a reversible air-cooled heat pump designed to ensure an high performance also in case of low ambient temperature, down to -5°C. These units are designed for applications that require reliability, continuity of operation and guarantee minimum consumption and high energy savings. In particular these units are designed for wineries and breweries to meet every requirement of the vinification cycle.

HFT SERIES consists of a reversible air-cooled heat pump designed to ensure an high performance also in case of low ambient temperature, down to -5°C. These units are designed for applications that require reliability, continuity of operation, temperatures stability, and guarantee minimum consumption and high energy savings.

HFTW SERIES  - consists of a reversible water-cooled heat pump designed for applications that require reliability, continuity of operation, high performance, reduced management costs and carbon dioxide emissions.

STANDARD CONFIGURATION: Compressors: Scroll. Condenser and fans: At costumer care. Evaporator: Coaxial (models 008÷100) or Shell & Tube (models 130÷430). Expansion Valve: Thermostatic. Protection Rating: IP54. Refrigerant: R410A, R454B; R32. Cooling Capacity Renge 7,4kw ÷ 375kw.

STANDARD CONFIGURATION: Compressors: Screw. Condenser and fans: At costumer care. Evaporator: Shell & Tube. Expansion Valve: Electronic. Protection Rating: IP54. Refrigerant: R134a; R513A and R1234ze. Cooling Capacity Renge 291kW ÷ 2240kW. Available with 1 , 2 or 3 Refrigerant Circuits.

STANDARD CONFIGURATION: Compressors: Scroll (models 061÷430). Condenser: At costumer care. Evaporator: 1x Brazed plate (CFTC.061÷185) 2x Brazed plate (CFTC.200÷430). Expansion Valve: Thermostatic. Fans: At costumer care. Protection Rating: IP54. Refrigerant: R410A, R454B; R32 (chiller provided with Nitrogen charge at 5 bars). Cooling Capacity Renge 50kW ÷ 370kW.

Our Series of Condensing Units represent a perfect example of energy efficiency. We have developed (not purchased) interactive thermodynamic cycle simulators capable of calculating an interesting thermodynamic equilibrium. We have testing stations that guarantee what has been designed and built. The Customer can attend the testing.
