Hydro Royal products

Heat Exchanger: Turbo Titanium. Compressor Type: Scroll. BTU Output: 49,000. COP: 5.3 (Coefficient of Performance). Max Circuit Performance: 50 AMP. Water Flow - Min/Max: 20-90 GPM. Plumbing Size: 2`. Thermostat Capacity: 10-40 C. Dual Thermostat: Yes. Weight (Shipping): 185 Lbs (215 Lbs). Size - W x H x D: 82 x 82 x 87 cm. Foot Print (D x W): 82 x 82 cm. Horsepower: 5.67.

Heat Exchanger: Turbo Titanium. Compressor Type: Scroll. BTU Output: 69,000. COP: 5.6 (Coefficient of Performance). Max Circuit Performance: 40 AMP. Water Flow - Min/Max: 20-90 GPM. Plumbing Size: 2". Thermostat Capacity: 10-40 C. Dual Thermostat: Yes. Weight (Shipping): 190 Lbs (220 Lbs). Size - W x H x D: 82 x 82 x 87 cm. Foot Print (D x W): 82 x 82 cm.

Heat Exchanger: Turbo Titanium. Compressor Type: Scroll. BTU Output: 40,000. COP: 5.9 (Coefficient of Performance). Max Circuit Performance: 30 AMP. Water Flow - Min/Max: 20-90 GPM. Plumbing Size: 2`. Thermostat Capacity: 10-40 C. Dual Thermostat: Yes. Weight (Shipping): 180 Lbs (210 Lbs). Size - W x H x D: 82 x 82 x 87 cm. Foot Print (D x W): 82 x 82 cm.

They said it couldn’t be done with titanium, but we took it a step further by rifling our titanium tubing, adding even greater efficiency in the heat exchange process. The Hydro Royal Hi-E Series of Swimming Pool Heat Pumps has exclusive, specially designed State Of The Art TXV (Thermal Expansion Valve) which has been optimized for R-410A Refrigerant to precisely regulate the flow of refrigerant through our patent pending coil to achieve maximum efficiency especially at lower temperatures, allowing lower cost of operation.

Heat Exchanger: 100 % Titanium Heat Exchanger. Min/Max Flow: 20/70 Gallons. Recommended Flow: 45 Gallons. Compressor: Scroll. Plumbing Size: 2". Min Amps / Max Breaker: 37 /40. Dimensions (Shipping): 31" x 31" x 38" (33" x 31" x 43"). Weight (Shipping): 219 Lbs. (255 lbs.).

HR-125-T-A - Heat & Cool. Heat Exchanger: 100 % Titanium Heat Exchanger. Min/Max Flow: 20/70 Gallons. Recommended Flow: 45 Gallons. Compressor: Scroll. Plumbing Size: 2". Min Amps / Max Breaker: 37 /50. Dimensions (Shipping): 31" x 31" x 38" (33" x 31" x 43"). Weight (Shipping): 218 Lbs. (253 lbs.).

Heat Exchanger: 100 % Titanium Heat Exchanger. Min/Max Flow: 20/70 Gallons. Recommended Flow: 45 Gallons. Compressor: Scroll. Plumbing Size: 2". Min Amps / Max Breaker: 37 /50. Dimensions (Shipping): 32" x 32" x 40" (33" x 31" x 43"). Weight (Shipping): 222 Lbs. (257 lbs.).

Heat Exchanger: 100% Titanium Heat Exchanger. Min/Max Flow: 20/70 Gallons. Recommended Flow: 45 Gallons. Compressor: Scroll. Plumbing Size: 2`. Min Amps / Max Breaker: 37/40. Dimensions (Shipping): 31` x 31` x 38` (33` x 31` x 43`). Weight (Shipping): 218 Lbs. (253 lbs.).

Heat Exchanger: 100% Titanium Heat Exchanger. Min/Max Flow: 20/70 Gallons. Recommended Flow: 45 Gallons. Compressor: Scroll. Plumbing Size: 2`. Min Amps / Max Breaker: 36 /40. Dimensions (Shipping): 31` x 31` x 34` (33` x 31` x 39`). Weight (Shipping): 210 Lbs. (245 lbs.).

HR-125-R-A - HEAT ONLY. Heat Exchanger: 100 % Titanium Heat Exchanger. Min/Max Flow: 20/70 Gallons. Recommended Flow: 45 Gallons. Compressor: Scroll. Plumbing Size: 2". Min Amps / Max Breaker: 37 /50. Dimensions (Shipping): 31" x 31" x 38" (33" x 31" x 43"). Weight (Shipping): 218 Lbs. (253 lbs.).
