Kiesler Machine Inc products

Fabricated from cold and hot rolled 1018 carbon steel. These high capacity weld-on hinges are provided with grease seals. Grease seals are used to ensure a long hinge life by keeping grease in and contamination out. Excellent choice lead filled radiation doors. Alloy steel pin.

Carbon steel hinges can be galvanized for high corrosion resistance and durability. This hinge is an ideal product for outdoor gates and doors. They are primarily used with gates and sheds. Carbon steel gate hinges can be designed for surface mounting applications. Alloy steel pin.

Manufactured from 1018 hot and cold rolled carbon steel with precision bearings. Available with or without mounting holes to be attached with doors weighting 800 LBS. Ideal for heavy duty vaults, detention, and complex industrial doors and gates. Offered in leaf thickness: 5/16". However, they can be manufactured in custom open leaf widths as per request. Alloy steel pin for years of trouble free service.

Manufactured exclusively for security purposes with non-removable pins. Primer finished for extended service life. Non-handed design allowing for both left and right hand mounting. Manufactured robustly to bear maximum door weight of 1,000 LBS and maximum radial load of 400 LBS.

Manufactured to high levels of quality using 1018 mild steel. Extensive load bearing capacity, hence, ideal for heavy duty industrial doors and gates. Non-handed for either left hand or right hand mounting. Available in width: 6", height: 5", and leaf thickness: 1/2". Alloy steel pin for years of trouble free service.

Proudly Made in the U.S.A. These hinges are manufactured from 1018 steel with hot and cold rolled steel. Supplied with or without mounting holes, per your requirements. The pins that turn on needle bearings of the hinges are exclusively fabricated with hardened and precision ground alloy steel pins. Grease seals are used to ensure a long hinge life by keeping grease in and contamination out. Our hinges are interchangeable with competitor’s hinges.

These hinges are designed for applications involving high radial loads, closers, and other heavy doors and gates. Sealed for life for years of maintenance free service. The hinge pin is constructed using heat treated alloy steel. Applications include Medical, military and defense and security.
