KRACHT GmbH products

KRACHT GmbH specializes in the development and production of customized pumps tailored to meet various fluid technology applications in collaboration with both national and international clients. The company provides a range of pump technologies, including transfer pumps, process pumps, hydraulic pumps, and special pumps. Additionally, KRACHT GmbH offers an array of fluid measurement technology such as gear type flow meters, screw type flow meters, turbine flow meters, and Coriolis mass flow meters. They also cover valve technology with products like pressure relief valves, pressure control valves, and universal valves. The drive technology segment includes hydraulic motors, flow dividers, and cylinders. Furthermore, KRACHT GmbH provides system technology solutions comprising oil supply systems, metering and mixing plants, hydraulic systems, and test bench construction. With a focus on industries such as marine, renewable energy, and process technology, KRACHT GmbH delivers technically advanced solutions suited for a variety of engineering challenges.

The gear type flow meters of the type VCA/VCN/VCG are flow meters for liquids with a certain lubricity. The measuring unit of the KRACHT volume counter consists of a pair of gears, driven by a liquid flow on the principle of a gear motor. The plain bearing provides both axial and radial support to the gears. The movement of the gears is sampled without contact by a sensor located in the cover.

Displacement : 97...1056cm3/r. Working pressure : ... 8 bar. Speed : _100 ...750 1/min. Viscosity : 76 ... 30 000 mmVs. Media temperature : -10...220°C.
