Layer Electronics S.r.l. products

The WINDSUN solar inverters are the latest generation of grid connected inverter, fed by solar modules or fuel cells. Thanks to its wide MPP operation voltage range, it starts supplying power from the first lights of the dawning up to late sunset, guaranteeing a higher power generation to your photovoltaic plant.

The electronic control circuit checks plant data and guarantees a reliable and completely automatic operation of the connected load.

The bidirectional electronic stabilizers SE Solar prevent the interface protection units from detaching, stabilizing the grid voltage. They can be installed in the following positions: a) Downstream of the exchange / sale energy meter (recommended) to stabilize both the user and the PV system; b) Inverter energy meter’s output to stabilize the PV system only; c) On the section that supplies the user to stabilize the user only.

Tested at field in the Italian “windy city” (Trapani, with its annual average wind speed of 6.8 m/s), LAYER wind generators have a mechanical robustness, that guarantees a high reliability that fears no comparison. Having a start-in wind speed of 3 m/s, our wind generators guarantee the operation even in the least windy zones.

The rectifier implements the very important function of brake system, that makes first of all safe a LAYER wind-power plant. Our electronic brake system decelerates wind generators immediately in a very reliable and safe way and, in the meantime, they continue to supply power to loads, with no any loss of power generation. Our electronic brake system works during a black-out and during strong gusts of wind. Moreover, our brake system avoids to let the generator rotate in overspeed, guaranteeing the absolute silence of our power plants.

The charge regulator implements the very important function of brake system, that makes first of all safe a LAYER wind-power plant. Our electronic brake system decelerates wind generators immediately in a very reliable and safe way and, in the meantime, they continue to supply power to loads, with no any loss of power generation. Our electronic brake system works at full recharge of batteries and during strong gusts of wind. Moreover, our brake system avoids to let the generator rotate in overspeed, guaranteeing the absolute silence of our power plants.

The DREPANUM wind inverters are the latest generation of grid connected inverter, fed by a wind generator. Unlike the other grid connected wind inverters on the market, our Drepanum wind inverters don’t result from solar inverters and are the only ones that implement an automatic wind MPPT (Maximum Power Point Tracking) algorithm, that allows to supply always the maximum power available from the generator under each wind speed. All the other inverters, instead, supply power to load in accordance with a predetermined power vs. frequency table, that doesn’t keep in mind of changeable conditions of the wind. Moreover, since LAYER wind generators can produce a higher power than the nominal one, our inverters are oversized to be able to supply higher power without any problem. Drepanum wind inverters can be customized for any horizontal or vertical-axle wind generator.
