10 products found
Linka Energy A/S Products
-
Hot Water Plant
Hot Water plants and High Pressure Hot Water plants are primarily used for heating residents, schools, industrial premises, stables etc., but can also be used for process heat.
-
Linka - Straw Boiler Plant: 100 - 15,000 kW
A straw boiler plant usually consists of the well-known Linka shredder with shredder drums. The straw is pulled upwards, ensuring that stones and other foreign objects are passed backwards from the shredder drums from where they can be removed. The shredder is produced in various sizes depending on the boiler size. The straw shredder is controlled by the load placed on the shredder drums, thus avoiding overloading the gear and motor. This ensures that the ...
-
Linka - Wood Chips Combustion Plant: 100 - 15,000 kW
A combustion plant based on wood chips consists of a scraper unit, which is sensibly located near the storage. 3 horizontal scrapers are positioned in the storage area which feed the chips to a sunken auger at the end of the scraper system. This auger is monitored by a photo cell. Whenever the auger is not filled, hydraulic cylinders will activate the scraper unit, and continue until the auger is refilled. The wood chips are transported through an ...
-
Linka - Wood Pellet Combustion Plant : 100 - 15,000 kW
A biomass plant based on wood pellets consists of a silo, which are made from either fibreglass for outdoor installations or fibreboard for indoors. The pellets are transported from the base of the silo by an auger to the boiler room, directly to a cell sluice and then into the boiler’s combustion hearth. When the boiler “calls” for fuel the feed procedure is activated, i.e. the feeding augers from the silo will start. The boiler is now ...
-
Steam Plant
For process industry, where higher temperatures or pressures are required, e.g. within the food and beverage sectors, laundry services, etc.
-
Linka - Wood Pellets Steam Plant: 400 - 15,000 kW
Linka’s steam system is largely identical with our hot water system. The difference is the design of the boiler, which is here made to produce steam. A combustion plant based on wood pellets consists of a silo, which are made from either fibreglass for outdoor installations or fibreboard for indoors. The pellets are transported from the base of the silo by an auger to the boiler room, directly to a cell sluice and then into the boiler’s ...
-
Heating Plant
For establishment or expansion of a joint heat supply in large or smaller cities.
-
Linka - Straw Heating Plant: 1,000 - 15,000 kW
here are several ways of constructing a straw system for a heating plant, depending on the customer’s requests and needs. Linka uses three basic construction methods, based on the chosen boiler size. All our plant sizes from 1000 to 15,000 kW can be built with a straw shredder. Due to the large quantity of straw, the feeding system can either be built with 2-3 levels of conveyors, from where the bales are lifted to the shredder by an elevator. ...
-
Linka - Wood Chips Heating Plant: 1,000 - 15,000 kW
There are several ways of constructing a heating plant system based on wood chips, depending on the customer’s requests and needs. Linka uses two basic construction methods, based on the chosen boiler size and the quality of the wood chips. Smaller plants are usually constructed with a scraper unit, which is sensibly located near the storage. Horizontal scrapers are positioned in the storage area which feed the chips to a sunken auger at the end of ...
-
Linka - Wood Pellet Heating Plant: 1,000 - 15,000 kW
A wood pellet plant consists of a silo, which are made from either fibreglass for outdoor installations or fibreboard for indoors. The pellets are transported from the base of the silo by an auger to the boiler room, directly to a cell sluice and then into the boiler’s combustion hearth. Wood pellets are produced all over Europe and are normally delivered from day to day. We are happy to help you decide the optimal storage size based on our plant ...
-
Mobile Heating Plants
For heat provision in inaccessible areas, satellite towns etc, where no main supply has been established, or for industrial premises where no boiler room is required.
-
Linka - Mobile Straw Heating Plant: 100 - 5,000 kW
With a Linka mobile plant you are ensured a turnkey heating plant, built in a large standard or custom container. A straw shredder and conveyor are installed outside the main container, along with a custom ash container and chimney. All of which are connected to the mobile plant’s main container. The main container is built in three sizes, depending on boiler size. It consists of a floor made of chequer plates, four sides in trapezoidal profiled ...
-
Linka - Mobile Wood Chips Heating Plant: 100 - 5,000 kW
With a Linka mobile plant you are ensured a turnkey heating plant, built in a large standard or custom container. A fuel container with a scraper unit is also installed, along with a custom ash container and chimney, all connected to the mobile plant’s main container. The main container is built in three sizes, depending on boiler size. It consists of a floor made of chequer plates, four sides in trapezoidal profiled sheets and a roof. The container ...
-
Linka - Mobile Wood Pellet Plant: 100 - 5,000 kW
With a Linka mobile plant you are ensured a turnkey heating plant, built in a large standard or custom container. A fuel container with a scraper unit is also installed, along with a custom ash container and chimney, all connected to the mobile plants main container. The main container is built in three sizes, depending on boiler size. It consists of a floor made of chequer plates, four sides in trapezoidal profiled sheets and a roof. The container is ...
