Mavel a.s. products

Runner Diameters 550 mm to 5500 mm. Number of Runner Blades 3, 4, 5 or 6. Head Range 1.5 to 35 meters (5 to 115 feet). Flow Range 1.2 to 200 cms (45 to 7060 cfs). Power Output Up to 20 MW.

Runner Diameters 1050 mm to 5500 mm. Number of Runner Blades 3 or 4. Head Range 1.5 to 12 meters (5 to 39.5 feet). Flow Range 15 to 150 cms (530 to 5340 cfs). Power Output 400 kW to 8 MW. Transmission Belt Drive or Parallel Gearbox.

Runner Diameters  1050 mm to 2500 mm. Number of Runner Blades  3 or 4. Head Range  1.5 to 12 meters (5 to 39.5 feet). Flow Range  5 to 45 cms (180 to 1590 cfs). Power Output  100 kW to 3 MW. Transmission  Direct Drive, Belt Drive or Bevel Gearbox.

Runner Diameters 710 mm to 3000 mm. Number of Runner Blades 4, 5 or 6. Head Range 2 to 35 meters (6.5 to 115 feet). Flow Range 2 to 60 cms (70 to 2120 cfs). Power Output 30 kW to 20 MW. Transmission Direct Drive.

Runner Diameters 400 mm to 1400 mm. Head Range 15 to 300 meters (50 to 1000 feet). Flow Range 0.5 to 20 cms (18 to 706 cfs). Power Output 100 kW to 12 MW. Transmission Runner Assembled to Generator or Turbine Shaft.

Runner Diameters 1000 mm to 2500 mm. Head Range Up to 300 meters (1000 feet). Flow Range Up to 35 cms (1236 cfs). Power Output Up to 30 MW. Transmission Runner Assembled to Generator or Turbine Shaft.

Runner Diameters 500 mm to 1800 mm. Number of Jets 1, 2 or 3. Head Range 50 to 1000 meters (165 to 3300 feet). Flow Range 0.1 to 6 cms (4 to 212 cfs). Power Output 30+ MW. Transmission Runner Assembled to Generator or Turbine Shaft.

Runner Diameters 500 mm to 2500 mm. Number of Jets 3, 4, 5 or 6. Head Range 50 to 1000 meters (165 to 3300 feet). Flow Range Up to 10 cms (353 cfs). Power Output 30+ MW. Transmission Runner Assembled to Generator or Turbine Shaft.

Head Range 1.5 to 6 meters (5 to 20 feet). Flow Range 0.15 to 0.4 cms (5 to 14 cfs). Power Output 5 to 20 kW.

Runner Diameters: 850 mm to 5500 mm. Number of Runner Blades: 4, 5 or 6. Head Range: 1.5 to 35 meters (5 to 115 feet). Flow Range: 3.5 to 200 cms (124 to 7060 cfs). Power Output: 70 kW to 20 MW. Transmission: Direct Drive, Belt Drive or Parallel Gearbox.
