Shenzhen Calinmeter Co,.ltd products

The meter is a split-type compact Din Rail mounted class 1 accuracy single phase electricity meter built in 35mm international standard housing made of poly-carbonate flame retardant materials. Galvanic isolation wire is basic connection between the meter and keypad. Double circuit measurement and relay are also available on request for reinforced tamper prevention.

The CA368 WS23 is a cost-effective solution for smart metering, data reading and load balance operations.The meter goes with four-wire direct connection type, 100 Amp per phase in a compact BS housing. It is ideal for large residential homes, small commercial and industrial applications. The meter is manufactured by ISO9001 standards and IP54 protection rating. It offers two way communication by DLMS/COSEM protocol via modular Ethernet/GPRS/PLC/RF com port and allows dynamic AMI interactions and reliable metrological operations at the same time.

The CA368-M is a tamper-proof reinforced  multi-function three phase four wire electric meter for commercial and inustrial metering environments. It supports unidirectional measurement of active and reactive energy and provides up to four tariffs. The meter operates in four-wire pattern in one, two or three phase configurations as well as three-wire partterns. The meter is compliant with  IEC 62053, EN 50670 (MID) in its mechanical spec and is intended to be installed in any situation that also meets these standards.

A CA368 and a customer interface unit (CIU) together makes the CA368-S,  a four-wire, 100 Amp per phase,split type  keypad based prepayment meter. The meter is finished in a compact BS footprint enclosure. It is ideal for residential homes, commercial and light industrial applications. The CIU is installed within customer`s premise and the main meter is usually locked away from consumers` premise in a kiosk, cabinet or meter box on the pavement or mounted on the pole. The main meter communicates with the CIU via Power Line Carrier, Radio Freqency, or LoRa, a low power consumption wireless technology. This non-wired split feature makes the meter immune to most tampers and facilitates quick and easy inspection by utility or service providers with no need to visit consumers.

Single Phase STS Prepaid Electricity Meter BS footprint Extended terminal cover steady broad voltage range. As the fundamental meter type of prepaid meter, the DDSY168 is designed and finished with a BS8565 standard housing and customer interface keypad. It operates with the current from 5 to 80Amp maximum.It is built with the rugged RF immunity withstand of 30V/m and IP54 rating, and therefore is able to operate in harsh environments. The meter is can be utilised as a credit meter as well as a prepayment meter to be vended with STS(Standard Transfer Specification) standard. The consumer can punch in the credit token number via the meter keypad to get  recharge.

Single Phase STS Prepaid Electricity Meter BS footprint Extended terminal cover steady broad voltage range. As the fundamental meter type of prepaid meter, the DDSY168 is designed and finished with a BS8565 standard housing and customer interface keypad. It operates with the current from 5 to 80Amp maximum.It is built with the rugged RF immunity withstand of 30V/m and IP54 rating, and therefore is able to operate in harsh environments. The meter is can be utilised as a credit meter as well as a prepayment meter to be vended with STS(Standard Transfer Specification) standard. The consumer can punch in the credit token number via the meter keypad to get  recharge.
