Shenzhen Meisongmao Industrial Co.,Ltd. products

Mechanical Characteristics: Cell Type Mono PERC 158.75-158.75mm. No.of Half-cells  120(6x20). Dimensions  1684x1002x35mm (66.30x39.45xl.38 inch). Weight  19.0 kg (41.9 lbs). Front Glass   3.2mm, Anti-Reflection Coatinq, High Transmission, Low Iron, Tempered Glass. Frame  Anodized Aluminium Alloy. Junction Box IP67 Rated. Outout Cables  TUV lx4.0mm,(+) 290mm, (-) 145mm or Customized Length.

Mechanical Characteristics: Cell Type Mono PERC 158.75x 158.75mm. NO.OT naii-Cells Dimensions 1ZV (0*ZUJ 1684x1002x35mm (66.30x39.45x1.38 inch). Weight 19.0 kg (41.9 lbs). Front Glass 3.2mm, Anti-Reflection Coating, High Transmission, Low Iron, Tempered Glass. Frame Anodized Aluminium Alloy. Junction Box IP67 Rated. Output Cables TUV lx4.0mmJ, (+) 290mm, (-) 145mm or Customized Length.

Mechanical Data: Solar cells  Monocrystalline 210x70mm. Cell configuration 150cells(5x15+5x15). Module dimensions 2220x1108x40mm. Weight 28.5kg. Superstrate High Transmission, Low Iron, Tempered ARC Glass. Substrate White Back-sheet
Frame Anodized Aluminium Alloy type 6063T5, Silver Color. J-Box Potted, IP68, 1500VDC, 3 Schottky bypass diodes. Cables 4.0mm2 (12AWG),  Positive(+) 270mm, Negative(-) 270mm. Connector Risen Twinsel PV-SY02, IP68.

Packaging Configuration 40ft(HQ): Number of modules per container 540. Number of modules per pallet 27. Number of pallets per container 20. Packaging box dimensions (LxWxH) in mm 2250x1130x1240. Box gross weight[kg) 825.

Mechanical Data  : Solar cells Monocrystalline, 9BB. Cell configuration 144 cells (6x12+6*12). Module dimensions 2015x996x40mm. Weight 23kg. Superstrata High Transmission, Low Iron, Tempered ARC Glass. Substrate White Back-sheet. Frame Anodized Aluminium Alloy type 6063T5. Silver Color. J-Box Potted, IP68,1500VDC, 3 Schottky bypass diodes. Cables 4.0mma (12AWG), Positive(+)270mm, Negative(-)270mm. Connector Risen Twinsel PV-SY02. IP68.

Temperature Ratings ( STC ): Temperature Coefficient of Isc +0.060%/C. Temperature Coefficient of Voc -0.300%/ C. Temperature Coefficient of Pmax -0.370%/ C.

Temperature Ratings ( STC ): Temperature Coefficient of Isc +0.060%/C. Temperature Coefficient of Voc -0.300%/ C. Temperature Coefficient of Pmax -0.370%/ C.

Mechanical Characteristics: Cell Type Poly-crystalline 157x157mm (6 inch).

Mechanical Characteristics: Cell Type Poly-crystalline 157x157mm (6 inch).

Mechanical Data: Solar cells Cast-Mono, 5BB. Cell configuration 72 cells (6x12). Module dimensions 1979x996x40mm. Weight 22.5kg. Superstrate High Transmission, Low Iron, Tempered ARC Glass. Substrate White Back-sheet. Frame Anodized Aluminium.  Alloy type 6063T5, Silver Color. J-Box Potted, IP68, 1500VDC, 3 Schottky bypass diodes. Cables 4.0mm (12AWG), 1200mm length. Connector Risen Twinsel PV-SY02, IP68.
