CE-D series is a 3 phase AC intelligent transducer with the programmable power, intelligent measurement, digital tube display, power accumulation, transmission output, switch output, RS485 output, measurement of four quadrant power and other function. It is with the advantage of high precision, strong electromagnetic compatibility.

CE-D series with MU4 case intelligent transducer functions programmable, true RMS measurement, digital tube display, power accumulation, the standard analog, switch, RS485 output. It makes the features of high precision, good electromagnetic compatibility, good looks and so on. Can set any one electrical parameter of voltage, current, power and power factor corresponding standard analog output according to the requirements. Can freely set the  corresponding limit value, hysteresis, upper limit alarm or lower limit alarm and other parameters of current  or voltage switching value,. Free to set the communication address (0-255), display variable ratio and so on. Press the "←" and "→" keys in front of the product panel to freely view the real-time values of voltage, current, active power, reactive power, power factor, frequency, and electrical measurement.

Three-phase AC digital display using high-speed digital signal processing chip and high-precision energy metering chip, can accurately and constantly measure the common power parameters in the power grid, three-phase voltage, three-phase current, active power of each phase, reactive power, inspecting power, power factor, active energy, reactive energy and grid frequency, it is with RS485 communication connection port, digital input and power pulse output and other functions.

This product is a power integrated measurement of single-phase digital isolation transducer. It can measure the full-parameter of the AC circuit. Using high-precision 24-bit dedicated AD chip, the ratio dynamic range can be up to 1000: 1, the measurement parameters are voltage, current, frequency, active power, reactive power, power factor, total accumulative energy and other electrical parameters with high accuracy, good stability and high communication speed, the completely isolated processing technology is with anti-interference ability. Measurement of electrical parameters through the RS-485 digital interface output to achieve long-distance transmission, the product MODBUS protocol is complete compatible with a variety of configuration software or PLC equipment MODBUS (RTU) protocol. It can be applied to power, room monitoring, industrial measurement and other fields.

This product is a 3-phase 3 wire digital isolation transducer of 3-phase power integrated measurement. The two- table method is used to measure the full-parameter of three-phase three-wire AC loop. Using high-precision 24-bit dedicated AD chip, the ratio dynamic range can be up to 1000: 1, the measurement parameters are voltage, current, frequency, active power, reactive power, power factor, total accumulative energy and other electrical parameters with high accuracy, good stability and high communication speed. The completely isolated processing technology is with anti-interference ability. Measurement of electrical parameters through the RS-485 digital interface output to achieve long-distance transmission, the product MODBUS protocol is complete compatible with a variety of configuration software or PLC equipment MODBUS (RTU) protocol. It can be applied to power, room monitoring, industrial measurement and other fields.

This product is a 3-phase power integrated measurement of 3-phase 3 wire digital isolation transducer. The two- table method is used to measure the full-parameter of three - phase three - wire AC loop. Using high-precision 24-bit dedicated AD chip, the ratio dynamic range can be up to 1000: 1, the measurement parameters are voltage, current, frequency, active power, reactive power, power factor, total accumulative energy and other electrical parameters with high accuracy, good stability and high communication speed. The completely isolated processing technology is with anti-interference ability. Measurement of electrical parameters through the RS-485 digital interface output to achieve long-distance transmission, the product MODBUS protocol is complete compatible with a variety of configuration software or PLC equipment MODBUS (RTU) protocol. It can be applied to power, room monitoring, industrial measurement and other fields.

This product is an electrical isolation transducer of single-phase active and reactive power measurement, complete isolation between input and output signals. Through the internal switch can be switched to active and reactive power measurement, with polarity switch-over measurement function simultaneously, can offer unipolarity or bipolarity measurements, no need to distinguish direction of current for unipolarity measurement. Can be widely used in electricity, communications, railways, industrial control and other fields.

This device is an electrical isolation transducer of 3-phase active, reactive power, power factor, and true RMS measurement. Its input is isolated from output signal, and output linear standard analog signal. Through the internal switch, can switch to active, reactive power and power factor measurement of 3-phase 3-wire and 3-phase 4-wire. The product can be widely used in electric power, communications, railway, industrial control and other fields.

This device is an electrical isolation transducer of DC power measurement. By converting the measured input voltage and current into DC power to transmit output, Through the internal switch can switch a variety of output types, while with polarity switching function can be unipolar or bipolar measurement, The product can be widely used in DC power supply cabinet and DC power supply system detecting.

This series of products use professional MCU and 24-bit high-precision AD for data acquisition, non-linear processing algorithms and isolated measurement of the various models of thermal resistance and thermocouple signals, The transmission output is standard DC signal of 0 ~ 20mA , 0 ~ 5V, 4 ~ 20mA or 1 ~ 5V, with high precision, high isolation, low power consumption, low drift, wide temperature range, strong anti-interference ability and so on. The transducer uses a fully isolated design, that is, input, output and power are isolated from each other, eliminating the mutual interference between the signals. This product is widely used in electric power, communication, railway, mining, metallurgy, transportation, instrumentation and other industries because of its ultra-thin housing DIN rail card-mounted structure, plug-in terminal wiring, installation and maintenance convenience.
