Siemens Energy Global GmbH & Co. KG products

Simple cycle output (ISO), 593 MW(e), Combined cycle efficiency: > 64%, Derived from proven H-class technology. The next generation of advanced air-cooled gas turbines. Our HL-class gas turbines are paving the way to the next level of efficiency and performance. Derived from proven H-class technology in an evolutionary development step, the next generation of advanced air-cooled gas turbines uses a series of new, but already tested technologies like super-efficient internal cooling features for blades or vanes and an advanced combustion system to increase firing temperature.

Well-proven H-class technology backed by largest commercially operating fleet experience in the market. Simple cycle power generation (ISO), 450 MW(e), Combined cycle efficiency: 62%, Powerful gas turbine for highly efficient combined cycle applications.

Trusted F-class technology for reliable performance. Simple cycle power generation (ISO), 385 MW(e), Combined cycle efficiency: 62%, Robust gas turbine with extensive fleet experience.

Outstanding in cogeneration and combined cycle applications. Simple cycle power generation (ISO) up to 62 MW(e). Combined cycle efficiency: >60%. A robust industrial gas turbine designed for flexibility.

Engineered for maximum flexibility. Simple cycle power generation (ISO) 39.8 MW(e), Mechanical drive: 41.0 MW. Top-class performance for oil and gas industry as well as industrial power generation.

Engineered for maximum flexibility, Simple cycle power generation (ISO) 32.8 MW(e), Mechanical drive: 33.7 MW. Highly fuel-flexible gas turbine, capable of dual fuel DLE.

Class leading gross electrical efficiency performance. Simple cycle power generation (ISO) up to 5.8 MW(e). Easily deployable for dependable, efficient and flexible heat and power.

A trusted choice, proven in critical operations. Simple cycle power generation (ISO) up to 37.2 MW(e). Mechanical drive: 38.5 MW. Qualified and proven in oil and gas applications, onshore and offshore.

A steam turbine with short start-up times and variable start-up modes to ensure grid stability. Siemens Energy Steam Turbines of the SST-5000 series are operated in combined cycle power plants (CCPP) and in steam power plants (SPP).
The SST-5000 steam turbine combined with a gas turbine, is able to achieve a net plant efficiency of more than 64 percent in combined cycle applications.

Siemens Energy Steam Turbines of the SST-6000 series are widely operated in steam power plants with a power output up to 1,200 MW and an efficiency up to more than 46 percent. Products of the SST-6000 series consist of a high-pressure turbine, an intermediate-pressure (IP) turbine, and up to three low-pressure turbines for 50 and 60 Hz. The SST-6000 is installed as a high-level arrangement with down exhaust. Various extractions (up to 10 stages) are possible for feed water preheating, process steam, and district heating. The installed capacity of SST-6000 all over the world is more than 100,000 MW.
