Sonya Ceramics products

All dimensions are in m.m. Tolerances for width and height ±0.3 mm, or 2% whichever is greater. Tolerances for length ±0.30 mm for all. Tolerances for holes and slots ±0.15mm. Bow allowances 0.15mm or 0.5% of the length.

All dimensions are in m.m. Tolerances for width ±0.3 mm and height ±0.2 mm, or 2% whichever is greater. Tolerances for length ±0.50 mm for all. Tolerances for holes and slots ±0.15mm. Bow allowances 0.15mm or 0.5% of the length.

All dimensions are in m.m. Tolerances for width and height ±0.3 mm, or 2% whichever is greater. Tolerances for length ±0.40 mm for all. Tolerances for holes and slots ±0.15 mm. Bow allowances 0.15 mm or 0.5% of the length.

All dimensions are in m.m. Tolerances for width and height ±0.3 mm, or 2% whichever is greater. Tolerances for length ±0.40 mm for all. Tolerances for holes and slots ±0.15 mm. Bow allowances 0.15 mm or 0.5% of the length.

All dimensions are in m.m. Dimensional tolerance: up to 5mm : ±0.15. From 5 to 10mm : ±0.20. Over 10 mm : ±2%. Detailed drawing available on request.

Cordierite materials are magnesium aluminosilicates which result from sintering soapstone with the addition of clay, Kaolin, corundum and mullite.
