Sun Ballast products

Sun Ballast 0 ° structure is an optimal solution when there are situations such as: limited floor load, limited spaces and landscape constraints. This specific solution achieves the goal of placing more panels in less space without it being visible from the outside. There is also a raised version in case you need to stand higher than the surface.

Sun Ballast 3 ° .K can be used for both single row installations and east-west orientations. The low inclination makes it possible to make installations that are not visible from the outside in cases where there are landscape constraints. It is also particularly suitable when there are load limits on the roof thanks to its limited weight.

Sun Ballast 5° Sail system has been designed to take advantage of all the available coverage surface by optimizing the construction of the photovoltaic system. This system allows to recover the area usually left for shading between the rows. With the same space you can get to install about 20% more modules compared to a traditional system. Also used in shorter sails or single rows allow you to raise the front of the plant up to 60 cm from the floor, reducing exposure to shadows given by any other structures present (railings, fireplaces, etc.). It is possible to place the panels both horizontally and vertically

Sun Ballast Connect system creates a grid composed of ballast and photovoltaic modules linked together, making the rows integral with each other. This guarantees a high wind resistance as confirmed by the meticulous tests with fluid dynamics simulators and structural yield stress, achieving excellent wind resistance results. All this in the face of weight kg/ sqm reduced. As a whole, the ballast plus modules, brings a load in coverage of about 15-20 kg/ sqm. Connect system is suitable for any type of framed module which can be laid horizontally with an inclination of 5 °, 10 °, 15 °, 20 ° and 30 °. In addition, for the 10 ° angle inclination, the solution for laying the photovoltaic modules vertically is also available.
