Viatronics Corp. products
ViaSite - Radar Speed Sign ViaSite
The Radar Sign ViaSite 32 Trinity displays vehicle speeds up to 199 KPH or MPH with clear visibility for drivers. Speeds within the limit are shown in green, while those exceeding the limit appear in red. This display can be equipped with data collection and wireless data transfer capabilities, as well as options for battery and solar panel power. The sign features a durable aluminum case with powder coating and a retroreflective sticker for enhanced visibility. The front shield is made of 5mm thick polycarbonate with an anti-reflective satin surface. Electrical protection is rated at IP56, ensuring reliable performance in various weather conditions. The LED digits, available in red, amber, and green, offer high brightness and are readable from a minimum distance of 150 meters. Speed measurements range from 1 to 199 KPH or MPH with an accuracy of ± 1 KPH (± 2 MPH). The sensor's range varies from 50-100 meters, with an extended range of up to 250 meters available. Operational temperatures range from -20 to +50 °C, and the sign can be powered by 12 VDC or 100-240 VAC, with optional battery and solar power solutions. Additionally, the sign features a continuous brightness adjustment capability and consumes less than 50 mA in standby mode. Easy to install, it includes flexible mounting brackets for poles.
ViaSite - Radar Sign for Speed Display
The Radar Sign ViaSite 32 Info is designed to display vehicle speeds up to 199 KPH or MPH, enhancing traffic safety by alerting drivers of their speed. Speeds under the limit are shown in green, while those exceeding the limit appear in red. This system can be optionally equipped with data collection and wireless data transfer capabilities, as well as being powered by batteries or solar panels. The mechanical specifications include a rugged aluminum case with a powder-coated finish, dimensions of 750 x 650 x 80 mm, and a durable 2 mm sheet metal aluminum construction. It features a 5 mm thick polycarbonate front shield with an anti-reflective surface and a retroreflective Class 1 sticker around the edge. The bi-color LED display provides high-brightness digits, with readability up to 150 meters and a viewing angle of 30 degrees. The device boasts an IP56 electrical protection rating and flexible mounting options for poles. Electrical specifications include a speed range of 1-199 KPH (or MPH), an accuracy of ±1 KPH (±2 MPH), and operational temperature between -20 to +50°C. The unit operates on 12 VDC or 100-240 VAC, with optional power sources including temporary AC, street lights, and solar power.
Viatronics - Speed Monitoring and Display System
The Speed Display ViaSite 32 Amber is a versatile speed monitoring and display system capable of showcasing speeds up to 99 KPH or MPH. The unit uses single amber-colored digits that flash when the detected speed surpasses the set limit, ensuring clear visibility and immediate feedback. It can be equipped with additional functionalities, including data collection, wireless data transfer, and options for battery and solar power. The rugged aluminum case with a powder-coated finish ensures durability, while a 5 mm thick polycarbonate front shield provides antireflective properties. It features a retroreflective Class 1 sticker for enhanced visibility, and customizable front decorations per customer requirements. With an IP56 rating, it guarantees protection against dust and strong water jets. The LED digit display is amber-colored, with digits 320 mm high, offering a viewing angle of 30 degrees and a minimum reading distance of 150 meters. The speed range is 1-99 KPH with an accuracy of ±1 KPH, and the measurement range varies from 50-250 meters depending on the sensor type. The temperature operating range is -30 to +50°C, and the unit supports power inputs of 12 VDC and 100-240 VAC. It weighs approximately 10 kg and can optionally include a 12VDC 20 Ah battery. The display also features brightness adjustment with a continuous characteristic and low standby power consumption of less than 50 mA at 12V DC. Installation is straightforward, and the unit includes a directional radar sensor.
