Yingli Green Energy Holding Co., Ltd. products

Dimensions : 1650mm / 992mm / 35mm. Module Type: YL295P-29b (1500V), with peak power of 295W. YL290P-29b (1500V), with peak power of 290W. YL285P-29b (1500V), with peak power of 285W. YL280P-29b (1500V), with peak power of 280W. YL275P-29b (1500V), with peak power of 275W. YL270P-29b (1500V), with peak power of 270W. Independently tested for proven product quality and long-term reliability. Millions of PV systems installed worldwide demonstrate Yingli`s industry leadership.

Dimensions : 1960mm / 992mm / 40mm. Module Type : YL345P-35b (1500V), with peak power of 345 W. YL340P-35b (1500V), with peak power of 340 W. YL335P-35b (1500V), with peak power of 335 W. YL330P-35b (1500V), with peak power of 330 W. YL325P-35b (1500V), with peak power of 325 W. YL320P-35b (1500V), with peak power of 320 W. Independently tested for proven product quality and long-term reliability. Millions of PV systems installed worldwide demonstrate Yingli`s industry leadership.

Dimensions : 1650mm / 992mm / 35mm. Module Type : YL315D-30b (1500V), with peak power of 315W. YL310D-30b (1500V), with peak power of 310W. YL305D-30b (1500V), with peak power of 305W. YL295D-30b (1500V), with peak power of 295W. YL290D-30b (1500V), with peak power of 290W. YL285D-30b (1500V), with peak power of 285W.  Choosing the best P-type monocrystalline cells, YLM series modules are making the best out of your system. Trust in the expertise of Yingli and well proven technology.

Dimensions : 1960mm / 992mm / 40mm. Module Type : YL375D-36b (1500V), with peak power of 375W. YL370D-36b (1500V), with peak power of 370W. YL365D-36b (1500V), with peak power of 365W. YL360D-36b (1500V), with peak power of 360W. YL350D-36b (1500V), with peak power of 350W. YL345D-36b (1500V), with peak power of 345W. YL340D-36b (1500V), with peak power of 340W. Choosing the best P-type monocrystalline cells, YLM series modules are making the best out of your system. Trust in the expertise of Yingli and well proven technology.

Dimensions: 1658mm / 992mm / 6mm (frameless), 1664mm / 998mm / 32mm (framed). Module Type: YL350CG2530L/F-1, with peak power of 350W. YL345CG2530L/F-1, with peak power of 345W. YL340CG2530L/F-1, with peak power of 340W. YL335CG2530L/F-1, with peak power of 335W. YL330CG2530L/F-1, with peak power of 330W. PANDA BIFACIAL modules generate power from the front side as well as from the back. Together with the cutting-edge PANDA n-type crystalline silicon solar cells, which wake up earlier than conventional p-type and go to sleep later, the energy yield can be highest increased by 30%.

Dimensions: 1978mm / 992mm / 6mm (frameless). 1984mm / 998mm / 32mm (framed). Module Type: YL415CG2536L/F-1, with peak power of 415W. YL410CG2536L/F-1, with peak power of 410W. YL405CG2536L/F-1, with peak power of 405W. YL400CG2536L/F-1, with peak power of 400W. YL395CG2536L/F-1, with peak power of 395W. PANDA BIFACIAL modules generate power from the front side as well as from the back. Together with the cutting-edge PANDA n-type crystalline silicon solar cells, which wake up earlier than conventional p-type and go to sleep later, the energy yield can be highest increased by 30%.

Dimensions : 1950mm / 1040mm / 6mm. Module Type : YL360CG2536L-2 1/2, with peak power of 360W. YL355CG2536L-2 1/2, with peak power of 355W. YL350CG2536L-2 1/2, with peak power of 350W. YL345CG2536L-2 1/2, with peak power of 345W. YL340CG2536L-2 1/2, with peak power of 340W. PANDA BIFACIAL modules generate power from the front as well as from the back side. Together with the cutting-edge PANDA N-type crystalline silicon solar cells, which wake up earlier than conventional P-type and go to sleep later, the energy yield can be increased to 30%. 5 Bus-bar half cells and series & parallel electrical structure can reduce CTM loss and increase module output power.

Dimensions : 1956mm / 1046mm / 32mm. Module Type :  YL360CG2536F-2 1/2, with peak power of 360W. YL355CG2536F-2 1/2, with peak power of 355W. YL350CG2536F-2 1/2, with peak power of 350W. YL345CG2536F-2 1/2, with peak power of 345W. YL340CG2536F-2 1/2, with peak power of 340W. PANDA BIFACIAL modules generate power from the front as well as from the back side. Together with the cutting-edge PANDA N-type crystalline silicon solar cells, which wake up earlier than conventional P-type and go to sleep later, the energy yield can be increased to 30%. 5 Bus-bar half cells and series & parallel electrical structure can reduce CTM loss and increase module output power.

Dimensions : 1680mm / 992mm / 35mm. Module Type: YL290PD-29b, with peak power of 290W. YL285PD-29b, with peak power of 285W. YL280PD-29b, with peak power of 280W. YL275PD-29b, with peak power of 275W. YL270PD-29b, with peak power of 270W. YL265PD-29b, with peak power of 265W. The circuit design of YGE series modules developed by Yingli has been optimized. Each of its cell has been improved by bypass design so that they can be used in more shadowy and complex areas. Meanwhile, in land scarcity areas, the distance between modules has been shortened to increase the installed capacity and thus further improve power generating capacity in a systematic way.

Dimensions : 2000mm / 992mm / 40mm. Module Type : YL345PD-35b, with peak power of 345W. YL340PD-35b, with peak power of 340W. YL335PD-35b, with peak power of 335W. YL330PD-35b, with peak power of 330W. YL325PD-35b, with peak power of 325W. YL320PD-35b, with peak power of 320W. The circuit design of YGE series modules developed by Yingli has been optimized. Each of its cell has been improved by bypass design so that they can be used in more shadowy and complex areas. Meanwhile, in land scarcity areas, the distance between modules has been shortened to increase the installed capacity and thus further improve power generating capacity in a systematic way.
