Zhejiang Great Electrical Co., Ltd. products

100A contact switching capability. Only impulse excitation needed, both for single and double coil. Low power consumption, small in size. Custom assemblies available with flexible wire and/or copper straps, and/or with integrated shunt. 4KV dielectric strength between coil and contacts. RoHS compliant. IEC62055-31 UC2 compliant. Outline dimensions: (39 x 30 x 16.8)mm.

50A contacts switching capability. Only impulse excitation needed, both for single and double coil. Low power consumption, strong load capability. Small in size, PCB type installation. 4KV dielectric strength between coil and contacts RoHS compliant. Outline dimensions: (39 x 30.2 x 15)mm.

25A contacts switching capability. Only impulse excitation needed, both for single and double coil. Low power consumption, strong load capability. Small in size, PCB type installation. 4KV dielectric strength between coil and contacts. RoHS compliant. Outline dimensions: (38.8 x 28.7 x 15)mm. VDE certificate NO.: 40039308.

5A two sets of contacts switching capability. 10A contact switching capability. Only impulse excitation needed, both for single and double coil. Low power consumption, small in size. Samll in size, PCB type installation. 4KV dielectric strength between coil and contacts. RoHS compliant. Outline dimensions: (25 x 13 x 17) mm. Patent number: 200420115716.8.

100A two sets of contact switching capability. Only impulse excitation needed, both for single and double coil. Low power consumption, small in size. Custom assemblies available with flexible wire and/or copper straps, and/or with integrated shunt. 4KV dielectric strength between coil and contacts. RoHS compliant. IEC62055-31 UC3 compliant. Outline dimensions: (70 x 52 x 22)mm.

200A contact switching capability. Only impulse excitation needed, both for single and double coil. Low power consumption, small in size. Safe and reliable, long life time. 4KV dielectric strength between coil and contacts. RoHS compliant. Outline dimensions: 1B:(82 x 52 x 30) mm, 2B:(82x66x30)mm.

120A three sets of contacts switching simultaneously, auxiliary contact can be added. Only impulse excitation needed, both for single and double coil. Custom assemblies available with flexible wire and/or copper straps, and/or with integrated shunt. 4KV dielectric strength between coil and contacts. RoHS compliant. Outline dimensions: (110 x 52 x 24)mm.

90A three sets of contacts switching capability. Apply to State Grid three-phase meter. Only impulse excitation needed, both for single and double coil. Low power consumption, small in size. Custom assemblies available with flexible wire and/or copper straps, and/or with integrated shunt. 4KV dielectric strength between coil and contacts. RoHS compliant. IEC62055-31 UC2 compliant. Outline dimensions: (98 x 41 x 36)mm.

150A three sets of contacts switching simultaneously, auxiliary contact can be added. Only impulse excitation needed, both for single and double coil. Low power consumption, small in size. Custom assemblies available with flexible wire and/or copper straps, and/or with integrated shunt. 4KV dielectric strength between coil and contacts. RoHS compliant. Outline dimensions: (125 x 72 x 34)mm.

100A contact switching capability. Only impulse excitation needed, both for single and double coil. Lowpower consumption, small in size. Custom assemblies available with flexible wire and/or copper straps, and/or with integrated shunt. 4KV dielectric strength between coil and contacts. RoHS compliant. Outline dimensions: (58 x 40 x 21)mm.
