CBS ArcSafe - Model PPE-Z - Brochure

2616 Sirius Road | Denton, TX 76208 | Ph: 877-4-SAFETY | Fx: 940-382-9435 | info@CBSArcSafe.comCBSArcSafe.comWHAT STANDS BETWEEN YOU AND ARC-FLASH DANGER ?WE DO.(877) 4-SAFETY( 8 7 7 ) 4 7 2 - 3 3 8 9CBSArcSafe.comAstro Controls, Inc.www.astrocontrols.comIrving, Texas – Ph: 800-289-2757Sales and service for all types of industrial molded-case circuit breakers, insulated case circuit breakers, and motor controls.CBS ArcSafe, Inc. www.CBSArcSafe.comDenton, Texas – Ph: 877-4-SAFETYRemote racking systems, remote switch actuators, and handheld motorized racking tools for low- and medium-voltage switchgear.CBS Nuclear Services, Inc. www.CBSNuclear.comMatthews, N.C. – Ph: 704-882-1875Specializes in shop and on-site field servicing of Class 1E safety-related low- and medium-voltage switchgear and circuit breakers. Also services industrial and non-nuclear-related circuit breakers and related switchgear and substations. CBS Power Products, Inc. www.CBSPowerProducts.comDallas, Texas – Ph: 940-665-4444New alternative utility and industrial power products: transformers, switchgear, and other power apparatus.Circuit Breaker Sales Co., Inc.www.circuitbreaker.com Gainesville, Texas – Ph: 800-232-5809World’s largest inventory of low- and medium-voltage circuit breakers. Millions of parts in stock. Complete service, remanufacture, upgrade, and life extension services. Match existing switchgear lineup.Circuit Breaker Sales & Repair, Inc. www.CBSalesAndRepair.comHouston, Texas – Ph: 281-479-4555Servicing the Gulf Coast with shop or field service, repair, upgrade, or replacement of power system apparatus.Circuit Breaker Sales & Service, Inc. www.cbs-florida.comLakeland, Fla. – Ph: 863-646-5099One-stop service for circuit breakers, switchgear, transformers, protective relays, loadbreak switches, motor controls, unit substations, renewal parts, and repair, upgrade, life extension, and maintenance services.Circuit Breaker Store, Inc. www.CircuitBreakerStore.comDenton, Texas – Ph: 855-227-8673Your online source for all Group CBS products, a powerful solutions provider with a specialty vendor network that can supply factory new, surplus new, and reconditioned circuit breakers, electrical distribution, control equipment, parts, and remote racking equipment.Reliable Electrical Testing Services, LLC www.ReliableElectricalTestingServices.comLa Porte, Texas – Ph: 713-254-0006On-site commissioning and acceptance testing of new installations and apparatus; or maintenance, troubleshooting, repair, and electrical testing of existing systems. Also professional electrical power engineering services to ensure the reliable, safe operation of electrical systems.Sentinel Power Services, Inc. www.SentinelPowerServices.comTulsa, Okla. – Ph: 800-831-9550Sentinel Power Services is an electrical power service company servicing the Central U.S with electrical engineering studies; on-site electrical testing, preventive maintenance and repair services; and repairing, building, and installing electrical power systems. Solid State Exchange & Repair, Inc. www.SolidStateRepair.comDenton, Texas – Ph: 877-874-7349Quality, reliabile, on-time service and support for all brands and types of solid state power electronics including circuit breaker trip devices, protective relays, motor overload relays, and rating plugs.Transformer Sales Co. www.TransformerSales.comGainesville, Texas – Ph: 940-665-4484 Offers a complete line of new, surplus, and reconditioned dry type, cast coil, and liquid-filled power transformers from 1000 to 5000 kVA with primary voltages from 2400 volts to 34.5kV.Vacuum Interrupters, Inc. www.VacuumInterruptersInc.comCarrollton, Texas – Ph: 214-442-5877Provides replacement vacuum interrupters (vacuum bottle interrupters) for virtually any manufacturer’s medium- voltage circuit breaker or contactor.Western Electrical Services, Inc.www.WesternElectricalServices.comPhoenix, Ariz. – Ph: 888-395-2021Serving the Southwest with superior quality on-site electrical testing, maintenance, and repair services as well as rebuild, upgrade, and life extension services for switchgear, circuit breakers, and motor control.Western Electrical Services, Inc.www.WesternElectricalServices.comSalt Lake City, Utah – Ph: 888-395-2021The only full-service electrical testing and maintenance company in the Intermountain region.Western Electrical Services, Inc.www.WesternElectricalServices.comSumner, Wash. – Ph: 888-395-2021The Northwest leader in electrical testing, maintenance, and power switchgear services providing on-site electrical testing and maintenance, electrical engineering studies, and sales, repair, upgrade, and life extension services of circuit breakers, switchgear, motor control, and transformers. Also custom manufacturing of engineered and reverse-engineered parts.Western Electrical Services, Inc.www.WesternElectricalServices.comVancouver, Wash. – Ph: 888-395-2021Utility class service provider to the Northwest T&D market.A ffI L I AT E S d I R E C To RyAS A GROUp CBS COmpANY, CBS ArcSafe®, Inc. provides you access to the industry’s largest inventory of low- and medium-voltage switchgear remote systems for racking and operations. We have parts, on-site service, and comprehensive shop repair, remanufacturing, and life-extension capabilities. CBS ArcSafe® products keep technicians well outside the arc-flash danger zone.We take pride in being available and capable of responding anytime, anywhere.? Group CBS members are located across the U.S.? Largest inventory of new, surplus, and reconditioned low- and medium-voltage power equipment and replacement parts available in North America? Servicing of Class 1E nuclear-rated switchgear and cir-cuit breakers (in compliance with 10CFR50 Appendix B)? Modern shop facilities with skilled engineers and technicians? Comprehensive quality repair, rebuild, retro-fit, retrofill, and life-extension capabilities? On-site scheduled or emergency field service? We rent most equipment in our vast inventory? Quick access to charter aircraft and hot-shot trucks for emergency requirementsCBS Safe®A Group CBS CompanyArcCBS Safe®A Group CBS CompanyArcCBS Safe®A Group CBS CompanyArcCBS ArcSafe InstituteInside the newly constructed 11,000-square-foot CBS ArcSafe Institute, our tech-nical staff will guide end users through the key features of their remote racking, switching, and operating equipment, including proper ways to maintain and store the equipment, as well as how to safely and most efficiently use the equip-ment with their switchgear.The hands-on training is not a “one-size-fits-all” approach; rather, it is tailored to each facility’s individual needs and requirements. This is a unique benefit to CBS ArcSafe customers made possible through our affiliation with Group CBS, which includes several electrical equipment suppliers and more than one million square feet of electrical inventory, including one of most extensive inventories of circuit breakers, switchgear, panel boards, and motor control centers in the U.S.At the conclusion of the training, end users are equipped with all the infor-mation needed to properly utilize their switchgear remotely from a distance and in the safest, most effective manner that exists today.CBS ArcSafe FacilitiesBased in Denton, Texas, CBS ArcSafe’s facilities comprise three buildings, including administrative and design offices, a warehouse and manufacturing plant, and our new CBS ArcSafe Institute for customer training.When visitors first arrive at CBS ArcSafe, they enter the 13,000-square-foot administrative, sales, research and development, and engineering offices. This location includes custom milling machines for R&D projects and custom single-use remote switching and handheld racking solutions designed to specific customer requirements, as well as cutting-edge computing, CAD design, and 3D printing additive manufacturing systems. Behind our administrative offices is a 9,500-square-foot warehouse comprising large-scale manufacturing, millwork, and testing equipment. All CBS ArcSafe products are produced 100% in the United States, ensuring the highest quality components and systems. CBS ArcSafe®, Inc.’s personnel are available to assist you at all times. For after-hours or emergency support, contact us 24/7 via our emergency phone number: (940) 736-0943. Assistance is also available from other Group CBS companies, which are listed on the back cover. We continue to develop new solutions for our customers on a daily basis. If you do not see what you need in our catalog, give us a call.RSO-IIID1. Operating pushbuttons, such as circuit breaker trip and close buttons2. Operating levers, such as those equipped on motor control centers3. Operating charging handles requiring single or multiple cycles4. Operating rotary switches, such as pistol-grip SBM switches5. Engaging or disengaging mechanical interlocks, such as cir-cuit breaker interlock foot-pedalsRSO-IV1. Works with RRS-3 Single-Use Remote Racking Systems2. Installing and removing any switchgear utilizing a rotary racking mechanism3. Installing and removing any switchgear utilizing a non-rotary racking mechanism4. Engaging or disengaging mechanical or electrical interlocks, such as circuit breaker interlock foot-pedals or buttonsoptional features? Radio remote with up to 300-foot range ? 24V DC LED light ? Wireless video camera system with LCD monitor ? Rugged protective case assemblyBenefits? Lightweight, portable construction ? Mechanical and/or electrical safety protection ? Adjustable to fit unique electrical equipment configurations ? Fast and easy to set up ? Reduced need for a full-body arc-flash suit ? Adds safety and helps comply with NFPA 70E ? No modifications required CBS ArcSafe® Remote Switch Actuators are designed to remotely charge, close, and/or trip various styles and types of electrical equipment. Any remote switch actuator can be custom built for any electrical device you have available. The remote switch actuators are most commonly assisted by strong magnets so that no modifications are required to your switchgear. This also allows operators to easily move the remote switch actuator from one breaker to another. Each CBS ArcSafe remote switch actuator is custom built to your electrical equipment so that it can safely operate outside the arc-flash boundary.Remote Switch Operators (RSO) Remote Switch Actuators (RSA)RSO: US Patent nO. 8,006,371B1CBS ArcSafe RSO® (Remote Switch Operator) systems enable service personnel to stand outside the arc-flash protection boundary while operating electrical equipment, reducing or eliminating the need for a full-body arc-flash hazard suit. The RSOs can be used in conjunction with the CBS ArcSafe remote racking system or independently as a stand-alone device. All CBS ArcSafe products are compatible with all switchgear manufacturers including: ? ABB ? Allis-Chalmers? Alstom? BBC ? Cutler-Hammer ? Eaton ? Federal Pacific Electric ? Federal Pioneer ? General Electric ? Hyundai? ITE ? McGraw-Edison? Merlin Gerin? Mitsubishi? Powell? Reyrolle? Siemens ? Siemens-Allis ? Square D ? Toshiba ? WestinghouseNOTE: All manufacturers’ names, trademarks, and part numbers are used for reference purposes only. CBS ArcSafe, Inc. is not an authorized distributor or representative of manufacturers shown. Designated trademarks, brand names and brands appearing herein are the property of their respective owners.RSO-IAR1. Operating pushbuttons, such as circuit breaker trip and close buttons2. Operating levers, such as those found on motor control center buckets3. Operating charging handles requiring single or multiple strokes4. Operating rotary and pistol-grip switches, such as breaker control switches5. Engaging or disengaging mechanical interlocks, such as circuit breaker interlock foot-pedalsrrs®-1 Remote Racking SystemFor Rotary Circuit BreakersBenefits? Remote operation places operator outside the arc-flash protection boundary? Compatible with low- and medium-voltage circuit breakers produced by all major switchgear manufacturers? Use with horizontal and vertical types of air, SF6, oil, and vacuum circuit breakers? Height and angle of the drive is easily adjusted? Quick-release drive shafts and couplings simplify setup? Redundant over-racking protection provided? Seamless transfer AC/DC power? Hand-truck design provides easy mobilityBy permitting the automatic racking of the circuit breaker from a remote location, the CBS ArcSafe® remote racking system replaces the manual racking operation and removes the operating personnel from manual contact with the circuit breaker. The unique design of the CBS ArcSafe remote racking system, with its specially manufactured drive shafts and tooling, enables the system to operate with all types of circuit breakers produced by the major switchgear manufacturers. The CBS ArcSafe remote racking system can operate with draw-out types of air, SF6, oil, and vacuum circuit breakers that have either a horizontal or vertical racking operation. US Patent nO. 8,151,452B2specifications Weight . . . 200 lbs Battery Life . . . > 50 Operations* SyStem VoLtage . . . 24V DC input VoLtage . . . 120±10% VAC, 47-63 Hz † maximum ac current . . . 12.2 A DriVe motor poWer . . . 250 W DriVe aSSemBLy SpeeD . . 80 RPM charge time . . . Approx. 6 hours DimenSionS . . . 74" H x 26" W x 38.1" D operating DiStance . . . 35 feet ‡* Number of operations is dependent on the nature of the operation† May be custom ordered to match different local power standards ‡ Standard configuration, contact CBS ArcSafe® for other optionsRRS-3 MBII RRS-3 MDS RRS-3 VBCBS ArcSafe Single-Use Remote Racking Systems (RRS-3s) are designed to remotely rack a single style of circuit breaker utilizing a portable, stand-alone device. The RRS-3 units are most commonly assisted by strong mag-nets, meaning that no modifications are required to the switchgear. This also allows operators to easily move the RRS-3 from one breaker to another.The RRS-3 system is an inexpensive single-application remote racking system that allows the operator to install and remove a breaker while standing 25 to 75 feet away with a hand-control unit. Each CBS ArcSafe RRS-3 is custom built to your electrical equipment so that it can safely operate your switchgear.Benefits? Lightweight, portable construction ? Mechanical and electrical safety protection ? Mechanical clutch over-racking protection ? Adjustable to fit unique equipment configurations ? Fast and easy to set up ? Reduced need for a full-body arc-flash suit ? Adds safety and helps comply with NFPA 70E ? No modifications requiredoptional features ? 25-foot pendant extensions ? 24V DC LED light ? Wireless video camera system with LCD monitor ? Rugged protective case assembly Weight . . . . 23 lbs Battery Life . . . . 8 amp-hours output VoLtage. . . . . 24V DC input VoLtage . . . . 100-240 VAC/ 50-60Hz fuLL LoaD ampS . . . . 2 A encLoSure rating . . . . Type 1 encLoSure materiaL . . . . Polypropylene copolymerRSO-IV for the RRS-3 All RRS-3s require the RSO-IV to operate. The RSO-IV is a rechargeable 24V DC power supply that, when used in conjunction with an appropriate RRS-3, will remotely perform any racking operation that would normally require local operation by trained personnel. Tasks the RSO and RRS-3s can perform include, but are not limited to, the following operations:1. Installing and removing any switchgear utilizing a rotary racking mechanism2. Installing and removing any switchgear utilizing a non-rotary racking mechanism3. Engaging or disengaging mechanical or electrical interlocks, such as circuit breaker interlock foot-pedals or buttonsNOTE: Some units will require the RSO-IV-NW; the RSO-IV-NW is an extension of the RSO-IV that allows the operator to operate interlocks. RSO-IV Patent PendIng max. oper. DiStance . . . . 300 Ft. (Line Of Sight) frequency . . . . Direct Sequence Spread Spectrum (DSSS) Technology operating temp. . . . . -4°F to 131°F tranSmitter poWer . . . . +3.6V to +4.5V (Three AAA Batteries) auto ShutDoWn . . . . 4 Minutes inDicatorS . . . . Green — Transmit Red — Receive Amber — Link LoW Battery Warning . . . 3.3V and Below (Green LED will blink approx. once per second regardless of operational status) LoW Battery ShutDoWn . 3.1V and Below tranSmitter Weight . . . . 7.2 Oz. tranSmitter Size . . . . 5.37” x 2.68” x 0.92” tranSmit Button Life . . . 5 Million OperationsRadio Remote Pendant Station NOTE: All manufacturers' names, trademarks, and part numbers are used for reference purposes only. CBS ArcSafe, Inc. is not an authorized distributor or representative of manufacturers shown. Designated trademarks, brand names, and brands appearing herein are the property of their respective owners. Single-Use Portable Remote Racking Systemsrrs®-3The CBS ArcSafe RRS-2 is a portable and highly configurable remote racking system built to rack all circuit breakers with non-rotary racking mechanisms while keeping the operator outside of the arc-flash boundary. The operator is able to manipulate the breaker-specific tooling, available for numerous makes and models of switchgear, via either a wired or wireless pendant station from up to 300 feet away. The RRS-2 is powered by a redundant AC/DC system that utilizes either standard AC power or the internal battery to run the unit. Absolutely no modifications to the switchgear or circuit breaker are necessary to perform remote racking with the RRS-2. Prior to ordering, CBS ArcSafe recommends an on-site evaluation be performed by a company representative in order to ensure the proper equipment may be provided for each customer based on their particular switchgear and specific requests.BenefitsSetup and operation of the RRS-2 BE are very similar to that of the standard RRS-2; allowing users who are familiar with RRS-2 operation to be able to transition between operation of the two easily with no additional training required. RRS-2 BE benefits include:? Control cabinet housing all of the electronics vital for operation has been integrated into a separate rugged case for simple transportation and storage? Large linear actuator has been replaced with a compact, adjustable travel linear actuator more suited to the forces required for MCC buckets instead of large breakers? Steel frame of the RRS-2 has been modified to accept the specialized tooling required for MCC bucket install and remove applications? Modular construction reduces weight compared to RRS-2 model? Dual-channel-enabled operation allows users to carefully control the MCC bucket install and remove operations? Intelligent AC/DC power system, allowing the unit to run on battery or AC power? Two-station high-reach vertical adjustment capable of reaching MCC buckets up to 80-inches high. Also included is a wireless remote control, allowing users to operate the unit from up to 300 feet awayBenefits? Ideal for applications where users must transport racking unit by themselves through tight spaces or up stairways? Utilizes same dual-redundant racking protection via the Current Control Module (CCM) and mechanical torque limiter, giving users two means of protection against damaging equipment during racking operations? Welded steel frame of the RRS-1 has been replaced with a lightweight, extruded aluminum frame that supports customization based on specific application requirements? Complete RRS-1 unit has been broken down into three modular systems on the RRS-1 LT to reduce the overall size and weight? Large drive motor has been upgraded to a compact, brushless, DC gear motor assembly? Height adjustment rail on the RRS-1 has been replaced with a lightweight, manually operated, quick-release slide assembly? Control cabinet housing all electronics vital for operation has been integrated into a separate rugged case for simple transportation and storage? Large rubber wheels have been upgraded with a smaller and lighter replacement? Intelligent AC/DC power system, allowing the unit to run on battery or AC power? Two-station high-reach vertical adjustment capable of reaching breaker racking mechanisms up to 80” high. Also included is a wireless remote control which allows users to operate the unit from up to 300 feet awayspecifications Weight . . . 135 lbs Battery Life . . . > 50 Operations* SyStem VoLtage . . . 24V DC input VoLtage . . . 120±10% VAC, 47-63 Hz † permiSSaBLe torque . . . 20 ft-lb DriVe motor poWer . . . 200 W DriVe aSSemBLy SpeeD. . . 60 RPM charge time . . . Approx. 4 hours DimenSionS . . . 60" H x 22" W x 27" D operating DiStance . . . 300 feet ‡The RRS-1 LT system is CBS ArcSafe's lightweight and compact counterpart to the industry-leading RRS-1 universal rotary remote racking system. The RRS-1 LT is designed specifically for applications and environments where a weight and/or size constraint may limit the use of the RRS-1. In order to meet the design requirements for the RRS-1 LT, CBS ArcSafe had to make major alterations to the unit in order to minimize the size and weight, therefore decreasing the rating of the unit. CBS ArcSafe recommends the RRS-1 LT be primarily used on low-voltage circuit breakers requiring no more than 20 ft-lb of racking torque. rrs®-2 Remote Racking SystemFor Extraction-Style Circuit BreakersThe RRS-2 BE is designed specifically for motor control center (MCC) bucket removal applications where users normally would be required to perform the install or remove operation manually — exposing them to the potential hazards of an arc flash and its lethal consequences. Designed to be extremely versatile, the RRS-2 BE is suited for use for all environments — from grueling applications in a power-generation facility to clean rooms at a high-tech manufacturing plant.specifications Weight . . . 105 lbs Battery Life . . . > 50 Operations* SyStem VoLtage . . . 24V DC input VoLtage . . . 120±10% VAC, 47-63 Hz † charge time . . . Approx. 4 hours DimenSionS . . . 74" H x 25" W x 32" D operating DiStance . . . 300 feet ‡*Number of operations is dependent on the nature of the operation†May be custom ordered to match different local power standards ‡Radio remote control standard on RRS-2 BEspecifications Weight . . . . . 160 lbs Battery Life . . . . . > 50 Operations* SyStem VoLtage . . . . . 24V DC input VoLtage . . . . . 120±10% VAC, 47-63 Hz † maximum ac current . . . . . 12.2 A ext. actuator force . . . . . 600 lb ext. actuator SpeeD . . . . . 1.0"/second charge time . . . . . Approx. 6 hours DimenSionS . . . . . 60" H x 26" W x 36" D operating DiStance . . . . . 35 feet ‡*Number of operations is dependent on the nature of the operation†May be custom ordered to match different local power standards ‡Standard configuration, contact CBS ArcSafe® for other options rrs®-2 Berrs®-1 ltoptional equipment Remote Racking SystemsFor Extraction-Style and Rotary-Type Circuit BreakersPneumatic TiresThe air-filled pneumatic tires provide a cushion-ing effect and reduce wear on the RRS unit dur-ing transport. Ideal for customer applications where transportation or use on uneven, rocky, or gravel surfaces is likely to occur.CCM Radio RemoteThe CCM radio remote option allows users to operate the RRS and monitor the racking status wirelessly from up to 300 feet away. Ideal for users with extended distance requirements or those who wish to monitor the status of the racking operation remotely.Water-Resistant CoverIt is recommended that the RRS be stored in a dry, temperature-con-trolled environment. However, because this is not always possible, CBS ArcSafe offers a water-re-sistant cover that protects the RRS from contact with small amounts of liquid from above.LED LightThe LED light accessory adds a forward-facing, high- intensity light source with pan and tilt capability to the front of the RRS. Ideal for personnel setting up the RRS or installing RRS tooling in low-light environments.Wireless/Wired Video SystemThe wireless/wired video system allows users to monitor the remote racking oper-ation from up to 300 feet away using an RRS-mounted camera and stand-alone monitor. Ideal for users who will be visually separated from the RRS during the remote operation.Wired Pendant ExtensionsThe wired pendant exten-sion(s) allows users to operate the RRS from extended distances while remaining tethered to the unit. Ideal for use in facili-ties with extended distance requirements that also restrict radio-controlled device transmission.Stair Climber RailsThe stair climber rails provide a low-friction surface for use when transporting the RRS up and down stairs and provide a level of protection to the control cabinet during everyday use. Ideal for applications requiring transportation up or down stairways.Power SlideThe power slide system utilizes a motor to raise and lower the drive assembly instead of the standard handle. Ideal for applications requiring users to quickly and easily switch between racking heights for different breakers.Magne-Blast Supervisory LinkThe MBSL option allows the RRS to interface with the pre-existing control circuit and cubi-cle-mounted limit switches within GE Magne-Blast gear. Ideal for users who want to control the RRS by utilizing the pre-ex-isting Magne-Blast control scheme.Low-Speed/JogThe low-speed/jog option consists of a high-torque/ low-speed gearbox, as well as manual jog control for the RRS operation. Ideal for applications requiring added torque output and/or more precise control.Front CastersThe front casters allow for maximum mobility even in the tightest spaces, sim-plifying installation and setup in these locations. Ideal for tight or con-strained areas where users may otherwise have diffi-culty maneuvering the RRS.Tether SystemThe tether kit is used to provide a universal link between the RRS and the electrical equipment being remotely racked. Ideal for users who wish to remotely rack breakers with mov-ing racking mechanisms.High LiftThe high lift option is required to remotely rack any equipment with a racking mechanism more than 66 inches off the ground. Ideal for users who wish to rack breakers with extremely high racking mechanisms that would otherwise cause issues during manual operation.Lightweight Remote Racking SystemFor Rotary Circuit BreakersRemote Racking SystemFor Motor Control Center Buckets OnlyAll CBS ArcSafe products are compatible with all switchgear manufacturers including: ? ABB ? Allis-Chalmers? Alstom? BBC ? Cutler-Hammer ? Eaton ? Federal Pacific Electric ? Federal Pioneer ? General Electric ? Hyundai? ITE ? McGraw-Edison? Merlin Gerin? Mitsubishi? Powell? Reyrolle? Siemens ? Siemens-Allis ? Square D ? Toshiba ? WestinghouseNOTE: All manufacturers’ names, trademarks, and part numbers are used for reference purposes only. CBS ArcSafe, Inc. is not an authorized distributor or representative of manufacturers shown. Designated trademarks, brand names and brands appearing herein are the property of their respective owners.
