Cylinder Filling Plants

www.ogsi.com1-800-414-OGSI • 716-564-51656474CYLINDEROGSI o?ers a complete line of cylinder ?lling plants [CFP’s]. ese plants can be designed to produce oxygen up to 93% (+3%) purity for most oxygen applications, including breathable hospital requirements.e oxygen purity from OGSI plants is typically at 93%, with the balance being even amounts of nitrogen and argon. Our standard oxygen purity meets the medical requirements of the US Pharmacopeial Convention [USP], Canadian Standards Association [CSA], and ISO 10083 [European] speci?cations. CFP output levels of CO and CO2 are far below allowable limits. Instrumentation and alarms for O2, CO and CO2 levels are included with most CFPs*.OGSI CFP’s include all the support equipment required such as air compressors, air dryers and oxygen compressors for complete turnkey systems. All models are factory tested, and most are skid mounted. ese plants are designed to be shipped in standard 20 or 40-ft ocean containers for worldwide transit. Onsite commissioning and training is available from an OGSI engineer. Electrical power and an enclosure for the plant are all that is required at the customer’s site to get started.Complete CFP’s that are capable of ?lling 1 to 180 cylinders per day are currently available in [11] standard sizes. e cylinder size referenced is *6m3 size [K or H size] oxygen cylinders. Custom sizes available.* Consult Factory for availability on each model.PRODUCT DATA SHEETOxygen Generating Systems Intl.FILLING PLANTS [CFP’S]*Consult factory for dimensions. Dimensions (length, width, and height) are measured in US inches. Weight is measured in US pounds (lbs).CYLINDER FILLING PLANT SIZESMODEL CYLDRs/DAYLENGTH(IN.)WIDTH(IN.)HEIGHT(IN.)WEIGHT(LBS.)CFP-100CFP-175CFP-250CFP-375CFP-500CFP-650CFP-1000CFP-1250CFP-1800*81020375060100120180104104104104144144144144TBD8282828282828282TBD758690939391124135TBD3,6004,1004,8005,6006,2006,90010,50011,20021,600Model CFP-650SAMPLE TAP BOX(O2, CO, AND CO2 MONITORING SYSTEM)MAIN ELECTRICAL DISTRIBUTION BOXAIR COMPRESSOROXYGEN GENERATOROXYGEN COMPRESSOROST(OXYGEN STORAGE TANK)AST(AIR STORAGE TANK)VACUUM PUMP10 VALVE OXYGEN MANIFOLD814 Wurlitzer Drive • North Tonawanda, New York 14120 USA 1-800-414-OGSI(6474) • Phone 716/564-5165 • Fax 716/564-5173 A Division of Audubon Machinery Corporation www.ogsi.com 112010CYLINDER FILLINGSTATION MODEL CFP-15+e CFP-15+ is the world’s smallest “turn-key” oxygen cylinder ?lling station. By generating medical grade oxygen onsite, you can immediately eliminate the high cost of oxygen delivery and start realizing a fast pay back on this economically priced model. No need to spend valuable time changing and returning heavy oxygen cylinders. e CFP-15+ can automatically re?ll your oxygen cylinders and it is extremely easy to set up and operate. BENEFITS OF THE CFP-15+:CYLINDER FILLINGSTATION MODEL CFP-15Me CFP-15M [military] combines the high pressure and variable ?ow rate available from an oxygen cylinder with the oxygen generation and replenishment of an oxygen concentrator. Empty oxygen cylinders become a thing of the past By simply connecting an empty oxygen cylinder(s) (up to two H-size at once) to its discharge line and turning it on, it will automatically re?ll them to 2200 psig. e CFP-15M turns itself o? once the desired level of pressure is reached. All this is a very mobile military grade package. BENEFITS OF THE CFP-15M:Model CFP-15+Model CFP-15M No more heavy lifting Fill cylinders directly on board an ambulance. Fill new composite cylinders. e CFP-15+ quali?es for grant funding through the O?ce of Domestic Preparedness [ODP] State Homeland Security and [FEMA] Federal Emergency Management Agency. Provides oxygen during emergencies with only air and electricity. Quiet and practically maintenance free. Generates medical grade oxygen [93% purity]. Easily transported to battle?eld hospitals. Can be assembled onto its own cart for mobility. Saves space and eliminates tripping hazards. Runs automatically and requires little attention. Shuts down if oxygen purity drops [using display and audible alarms].
