Field-oriented Vector Inverter ADV200

2011EnglishAC Inverter • System series SIEIDrive ADV200The next generation...23WarrantyyearsSIEIDrive - ADV200AC Inverter • Flux Vector ControlThe new inverter series “SIEIDrive ADV200” represents an innovative con-cept in drive technology, as a result of the constant technological research and of the experience that the Gefran Group has acquired keeping a constant presence aside that of the major sector players.The new range has been engineered and developed to satisfy the real needs of System Integrators and OEM’s in order to provide them the best innova-tions and economical competitiveness in the international markets.Based on full mechanical modularity and on a powerful, intuitive and “fully open” programming platform, ADV200 offers absolute integration flexibility with high-end performance in any system architectures of the most advanced automation environments.The “Powerful Platform” for advanced automationSIEIDrive ADV2002AC mains supply(V)Power range ADV200 (kW)0.75 1.52.23.04.05.57.511 15 18.522 30 37 45 55 75 90 110132160200250315355...230400 Size 1 Size 2 Size 3 Size 4 Size 5 Size 6 Size 7575690On progress powers up to 1.5MW.... Versatile, Powerful, Reliable7General Characteristics? AC mains supply 400Vac…690Vac, 50/60Hz? Power range from 0.75kW to 1.2MW? Control mode • FOC Open Loop• FOC with Speed Feedback• V/f and V/f with feedback• PM Synchronous (on development)? Overload according with IEC146 Class 1 and Class 2? Heavy and Light overload management? Up to 4 options on board? Fieldbus • CANopen ®• DeviceNet• Profibus DP• Ethernet real.time GDNet? The "Safety Stop" card is compliant with machine safety directives and meets the following standards: PL=d under EN ISO 13849-1, SIL 2 under IEC 61508 and EN 954-1 Cat. 3.? Multilanguage programming software (5 languages)? Advanced PLC according with the IEC61131-3 Standard? IP20 standard protection degree? NEMA 1 protection degree with optional kitSIEIDrive - ADV200AC Inverter • Flux Vector ControlApplicationsSIEIDrive - ADV200AC Inverter • Flux Vector ControlModularity An innovative concept of integrated technology that offers full modularity. Mountable side by side and with accessories specifically dedicated to system solutions , ADV200 has been engineered to make installation easy for any operator, both in existing systems and in specific machine solu-tions, always offering a real reduction of required space in the cabinet and the best man-ageability.3Smart Connections Dedicated accessories and fully removable terminals, ensure simple and fast installation and start-up in compliance with the EMC normative.Fast Access Structured to of-fer simple and fast management of the product in any situa-tion of installation and mounting. From the terminal access to the rack assembling of the op-tions, each operation is quick and easy.Integrated Quality ADV200 integrates the fundamental de-vices for an absolute quality level, such as the DC choke that ensures maximum reli-ability in any conditions of working and the in-put filter that renders the drive in compliance with the EMC norma-tive EN61800-3.4Options ADV200 manages up to 3 option cards:Safety Card Integrated on board the drive as the 4th option, the EXP- SFTy card allows the motor to be disabled without the use of a safety contactor on the drive output. It guarantees compli-ance with the machine safety directive and meets the following standards:• PL=d under EN ISO 13849-1• SIL 2 under IEC 61508• EN 954-1 Cat. 3.Serial Line Integrated standard RS485 serial line with Modbus RTU protocol, for peer-to-peer or multidrop connec-tions (with OPT-485-ADV card).Back-Up Supply ADV200 can be supplied through an external +24Vdc supply in order to be kept active in case of mains input loss, ensuring in this situation the opera-tion of all monitoring functions, programming and any connected fieldbus network.• Encoder interface• Fieldbus interface • I/O expansionsModbus Cables shield OMEGA clamp to grounding 360° of shielded cables.SIEIDrive - ADV200AC Inverter • Flux Vector Control65Programming Keypad The man/machine interface is simple, fast and very functional thanks to the programming keypad KB_ADV.Programming Software Structured with 2 setting modes Easy and Export, to satisfy each level of user’s skill and programming needs both for complex or easy installation.A powerful platform but at the same time with a structure of menu/parameters that offers quick understanding, also facilitated by functionality of the keypad and the display.Intuitive navigation and easy start-up function thanks to the “Wizard” tool.ADV200 offers as standard 5 language programming (IT-ENG-FR-GER-SP) and the setup of “customizable menu”PC Configuration Tool “GF-eXpress” All drives of the SIEIDrive series and the automation devices of the Gefran Group (PLC, HMI, Instrumentation, etc) can be programmed by the use of the PC tool GF-eXpress. Advanced Development Environment “MDPLC” The advanced environment MDPLC is an integrated tool for the develop-ment of sophisticated application solutions, downloadable directly into the drive control board. The MDPLC structure is in compliance with all the PLC languages according to the international standard IEC 61131-3.• 4 lines display for 25 charac-ters• Clear alphanumeric text • Full information of any param-eters• Fast Navigating Keys • Custom Menu recalling Key• Upload - Download and stor-age of 5 complete sets of drive parameters• Remotable up to 10 meters• Programming through parameter list or block diagrams• Modbus RTU interface• Management of the file from the drive or the memory keypad• Integrated oscilloscope• Tool configurable in 5 languages.SIEIDrive - ADV200AC Inverter • Flux Vector Control6Technical DataPerformance ADV200 offers the most advanced control technology thanks to a powerful 32 bit microcontroller, able to provide high performances in terms of motor control and accuracy contemporary with the management of today’s sophisticated application systems.Control mode Speed regulation accuracy (*) Control Range? Accuracy • FOC with Speed feedback ± 0,01% Rated motor speed 1 : 1000• FOC open loop ± 30% Rated motor slip 1 : 100(*) referred to standard 4 poles motor • V/F ± 60% Rated motor slip 1 : 30Standard Configuration Setting ? KB_ADV programming keypad integrated? Regulation Stage • 2 Bipolar Analogue Inputs (Voltage/Current)• 2 Bipolar Analogue Outputs (1: Voltage/Current, 1: Voltage)• 6 Digital Inputs (PNP / NPN)• 2 Digital Outputs (PNP / NPN)• 2 Relay Outputs, single contact• RS485 Serial Line (Modbus RTU protocol)? Power Stage • DC Choke integrated• EMC Filter integrated• Dynamic Braking Module integrated (up to 55kW)Standards ? Immunity / Emissions CEE - EN 61800-3? Programming according to IEC 61131-3? Safety standard STO (Safe Torque Off): EN ISO 13849-1 PL=d, IEC 61508 SIL 2, EN 954-1 Cat. 3Environmental Condition ? Enclosures IP20 (IP54 dedicated series)? Ambient temperature -10°C ...+40°C, +40°C…+50°C with derating? Altitude Max 2000 m (up to 1000 m without current limitation)Approvals in compliance with CEE directives, for low voltage devices. , in compliance with American and Canadian market directivesGEFRAN S.p.A. has a policy of the continuous improvement of performance and range of our products and therefore the Company retains the right to modify products, data and dimen-sions without notice. Although the data and information contained in this document is as accurate as we can make it, it is intended to be used for product description purposes only and must not be interpreted as being legally declared specifications.Sizes - ADV 1007101510221030104020552075211031503185322043004370445055505750590061100613207160072000725007315073550Uln AC input voltage Vac 400 Vac -15% ... 480 Vac +10%, 3 phAC input frequency Hz 50/60 Hz, ± 5%• CT : Costant Torque (150% overload)AC Input Current for continuous service A 2.1 3.7 4.9 6.5 8.1 11.1 14 19.6 26.4 32.3 39 53 64 74 100 143 171 200 238 300 350 420 580 640Inverter Output for continuous service kVA 1.7 3 4 5.3 6.6 9 11.4 15.9 21.5 26.3 32 43 52 60 73 104 125 145 173 208 267 319 409 450Pn mot (Recommended motor output, fsw = default):@ Uln = 400 Vac kW 0.75 1.5 2.2 3 4 5.5 7.5 11 15 18.5 22 30 37 45 55 75 90 110 132 160 200 250 315 355@ Uln = 460 Vac Hp 1 2 3 5 5 7.5 10 15 20 25 30 40 50 60 75 100 125 150 175 200 250 300 400 450I2n Rated Output current:@ Uln = 400 Vac A 2.5 4.3 5.8 7.6 9.5 13 16.5 23 31 38 46 62 75 87 105 150 180 210 250 300 385 460 590 650@ Uln = 460 Vac A 2.3 3.9 5.2 6.8 8.6 11.7 14.9 20.7 27.9 34.2 41.4 55.8 67.5 78 94.5 135 162 189 225 270 347 414 531 585• VT : Variable Torque (110% overload)AC Input Current for continuous service A 3.7 4.9 6.5 8.1 11.1 14 19.6 26.4 32.3 39 53 64 74 89 143 171 200 238 285 350 420 540 640 710Inverter Output for continuous service kVA 3 4 5.3 6.6 9 11.4 15.9 21.5 26.3 32 43 52 60 73 104 125 145 173 208 267 319 409 450 506Pn mot (Recommended motor output, fsw = default):@ Uln = 400 Vac kW 1.5 2.2 3 4 5.5 7.5 11 15 18.5 22 30 37 45 55 75 90 110 132 160 200 250 315 355 400@ Uln = 460 Vac Hp 2 3 5 5 7.5 10 15 20 25 30 40 50 60 75 100 125 150 175 200 250 300 400 450 500I2n Rated Output current:@ Uln = 400 Vac A 4.3 5.8 7.6 9.5 13 16.5 23 31 38 46 62 75 87 105 150 180 210 250 300 385 460 590 650 730@ Uln = 460 Vac A 3.9 5.2 6.8 8.6 11.7 14.9 20.7 27.9 34.2 41.4 55.8 67.5 78.3 94.5 135 162 189 225 270 347 414 531 585 657• Overload : Heavy duty150% * In (1 ' each 5') A 3.75 6.5 8.7 11.4 14.3 19.5 24.7 34.5 46.5 57 69 93 113 131 157 225 270 315 375 450 578 690 885 975180% * In (0.5 " each 5') A 4.5 7.7 10.4 13.7 17.1 23.4 29.7 41.4 55.8 68.4 82.8 111.6 135 157 189 270 324 378 450 540 693 828 1062 1170• Overload : Normal duty110% * In (1 ' each 5') A 4.7 6.4 8.4 10.5 14.3 18.1 25.3 34.1 41.8 50.6 68.2 82.5 95.7 116 165 198 231 275 330 424 506 649 715 803U2 Max output voltage V 0.98 x Uln (AC Input voltage)f2 Max output frequency Hz 500fsw Switching frequency (Default) 8 8 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 2 2 2 2fsw Switching frequency (Max) 12 12 12 12 12 12 12 12 12 12 12 12 12 8 8 8 8 8 8 4 4 2 2 2Dimensions(width x heigth x depth) mm 120 x 320 x 235.1 150 x 392 x 250.1 180 x 517 x 250.1 268 x 616 x 270 300 x 680 x 325410 x 894 x 359 400 x 1200 x 485417 x 1264 x 485inches 4.72 x 12.6 x 9.26 5.91 x 15.43 x 9.85 7.09 x 20.35 x 9.85 10.55 x 24.25 x 10.63 11.81 x 26.77 x 12.816.1 x 35.2 x 14.115.75 x 47.24 x 19.0916.42 x 49.76 x 19.09Weight kg 5.8 10.2 16.4 22 32 60 90 130 140 150lbs 12.8 22.5 36.2 48.5 70.6 132.3 198.4 286.6 308.7 330.7 Rev. 0.6 - 13-12-20111S9D31GEFRAN S.p.A.Via Sebina 7425050 Provaglio d’Iseo (BS) ITALYPh. +39 030 98881Fax +39 030 9839063info@gefran.comwww.gefran.comDrive & Motion Control UnitVia Carducci 2421040 Gerenzano [VA] ITALYPh. +39 02 967601Fax +39 02 9682653infomotion@gefran.comTechnical Assistance : technohelp@gefran.comCustomer Service : motioncustomer@gefran.comPh. +39 02 96760500Fax +39 02 96760278Gefran worldwideGEFRAN BENELUXLammerdries-Zuid, 14AB-2250 OLENPh. +32 (0) 14248181Fax. +32 (0) 14248180info@gefran.beGEFRAN BRASILELETROELETRÔNICAAvenida Dr. Altino Arantes,377/379 Vila Clementino04042-032 SÂO PAULO - SPPh. +55 (0) 1155851133Fax +55 (0) 1132974012gefran@gefran.com.brGEFRAN DEUTSCHLANDPhilipp-Reis-Straße 9a63500 SELIGENSTADTPh. +49 (0) 61828090Fax +49 (0) 6182809222vertrieb@gefran.deSIEI AREG - GERMANYGottlieb-Daimler-Strasse 17/3D-74385 PleidelsheimPh. +49 7144 89 736 0 Fax +49 7144 89 736 97info@sieiareg.deGEFRAN ESPAñA C/ de Vic, 109-11108160 Montmeló (BARCELONA)Ph. +34 934982643Fax +34 935721571 comercial.espana@gefran.esGEFRAN FRANCE4, rue Jean Desparmet - BP 823769355 LYON Cedex 08Ph. +33 (0) 478770300Fax +33 (0) 478770320commercial@gefran.frGEFRAN SUISSE SARue Fritz Courvoisier 402302 La Chaux-de-FondsPh. +41 (0) 329684955Fax +41 (0) 329683574office@gefran.chGEFRAN - UK Ltd.Capital House, Hadley Park East,TELFORD, TF1 6QJPh. +44 (0) 845 2604555Fax +44 (0) 845 2604556sales@gefran.co.ukGEFRAN Inc.8 Lowell AvenueWINCHESTER - MA 01890Toll Free 1-888-888-4474Ph. +1 (781) 7295249Fax +1 (781) 7291468info@gefraninc.comGEFRAN SIEI - ASIABlk. 30 Loyang way 03-19 Loyang Industrial Estate 508769 SINGAPORE Ph. +65 6 8418300 Fax. +65 6 7428300 info@gefransiei.com.sgGEFRAN SIEI Drives Technology (Shanghai) Co., Ltd.No. 1285, Beihe Road, Jiading District, Shanghai, China 201807Ph. +86 21 69169898Fax +86 21 69169333info@gefransiei.com.cnGEFRAN SIEI Electric (Shanghai) Pte. Ltd.No. 1285, Beihe Road, Jiading District, Shanghai, China 201807Ph. +86 21 69169898Fax +86 21 69169333info@gefransiei.com.cnGEFRAN INDIA Pvt. Ltd.Head office (Pune office)Survey No: 182/1 KH, Bhukum, Paud road, Taluka – Mulshi, Pune - 411 042. MH, INDIAPh:+91-20-3939 4400Fax: +91-20-3939 4401gefran.india@gefran.inBranch office (Mumbai office) Laxmi Palace, M.G. RoadNaupada, Thane (W)400602 MumbaiPh. +91 22 2540 3384Ph. +91 22 2542 6640 Fax +91 22 2542 7889 support.india@gefran.inAUTHORIZED DISTRIBUTORSArgentinaAustraliaAustria Bosnia and HerzegovinaBrazilCanada ChileChinaColombia CroatiaCzech RepublicDenmark FinlandGreeceHungary IranIsraelItaly JapanJordanKorea KosovoLebanon Macedonia MalaysiaMarocMexico MontenegroNew ZealandNorway PolandPortugalRomania RussiaSaudi ArabiaSerbia SingaporeSlovakia RepublicSlovenia South AfricaSri LankaSweden SwitzerlandTaiwanThailand TunisiaTurkeyUkraine United Arab EmiratesUnited KingdomVenezuela ISO 9001FM 38167
