FlowCenter - Model BGM-255 - Double Pump - Brochure

REV-8-07 BGM 255 Geothermal Loop Pump Module PERFORMANCE CHARACTERISTIC CURVE 01020304050607080901000 10 20 30 40 50Flow - gpmTotal Head - feet PRODUCT FEATURES • Fully insulated cabinet eliminates condensation • No assembly required • Each unit has been leak tested • Full flow 1 1/8? brass valves • Standard 1? NPT connections • Compatible with all industry components • Functions smoothly and quietly • Easy access to valves and circulators for ease of service • 14 ¾? x 13 ¼? x 9¾? unit size makes for a compact unit • Installation hose kit available • Five year parts & labor warranty BGM 255 Geothermal Loop Pump Module OPERATION The circulator pump in this geothermal loop pump energizes and circulates the liquid through a geothermal heat pump and the earth loop. This results in the transfer of heat. INSTALLATION Wall Mounting Designed for quick and easy installation, the BGM series loop pump can be attached to most any wall using the screws and the mounting holes provided on the back of the unit. Connections and Hoses External connections are standard 1” NPT to accommodate industry standard fittings. Flow Center Products stocks and distributes hose kits for leading brands of geothermal heat pumps. Filling and Flushing Filling and flushing of the BGM series modules occurs through the connections at front. To direct flow, the module’s two brass valves rotate to four positions. Local Codes Flow Center products meet or exceed most city and state building codes, but it is recommended that installers always check local city installation requirements that may be unique to their geographic region. SPECIFICATIONS Module Dimensions 14 ¾? x 13 ¼? x 9¾? Available Bell & Gossett Circulators All Circulators 1 Phase 60 Hz PL55 115 VAC 9.4 A (2 pumps) Cast Iron PL55 230 VAC 4.8 A (2 pumps) Cast Iron PL55B 230 VAC 4.8 A (2 pumps) Bronze Approved Liquid Solutions Methanol, Exoendosol, Propylene Glycol Additional Information Minimum Valve Bore: 1 1/8? External Piping Connections 1” NPT Maximum Operating Pressure: 150 PSI Minimum Operating Temperature: 0 F Maximum Operating Temperature: 225 F Weight: 55 lbs. Flow Center Products, Inc. 119 W 580 N Crawfordsville, IN 47933 Telephone 866-364-9460 Fax 765-364-9462 Email rklaty@flowcenterproducts.com Website www.flowcenterproducts.com
