G25WMI-2A-T4 - Mobile Generators - Brochure

©2012 Doosan Infracore Portable Power • G25-G570 Mobile Generators (12/12)Member ofProud sponsor of Doosan Infracore Portable Power1293 Glenway DriveStatesville, NC 28625DoosanPortablePower.comExperience Doosan Portable Power and our industry-leading support and service. Whatever the job, we have the solution. From our comprehensive range of air compressors, lighting systems and generators to our rugged and reliable light compaction equipment, we have a solution to fit your needs. Running a successful business takes more than powerful equipment. That’s why Doosan Portable Power partners with an experienced global dealer network to stand beside you every step of the way. Doosan Portable Power — more than 100 years of providing excellence.Product improvement is a continuous goal at Doosan Infracore Portable Power. Specifications and design are subject to change without notice or obligation. DOOSAN and the Doosan logo are trademarks of Doosan Corporation.Portable PowerG25 - G570 | Mobile GeneratorsStrong Powertrains You Can Depend OnBecause the best mobile generators need the best powertrains, Doosan Portable Power selected global leaders to partner with for engines and powerful alternators. Robust, fuel efficient and emissions compliant engines are selected to ensure maximum uptime and low cost of ownership while our alternators feature AREP excitation to give unmatched performance in motor starting and voltage stability; perfectly suited for powering pumps, compressors and other job site needs.Rugged, Reliable and Environmentally FriendlyDoosan Portable Power products are designed for years of power and performance in some of the harshest conditions anywhere. Units are built on heavy-duty skidbases with an integrated 24-hour capacity fuel cell and feature the toughest running gear components for safe and trouble-free towing, on- or off-road. The enclosure is built from heavy-gauge steel and finished with a 13-stage powder coat process to provide the ultimate corrosion protection. Plus, Doosan brings to market the only mobile generator line that includes environmental containment as a standard feature on all models so you can be assured there will be no potential for spilled fuel or oil to cause job site contamination. Because It’s All About UptimeWhen it is freezing outside and a sluggish generator is unacceptable, Doosan Portable Power’s Tundra PackageTM keeps the machine warm and running with uncompromising performance. Our engineers identified the essential parts of the generator that must stay warm so that the generator starts quickly every time and never freezes. For reliable performance down to -40°F/°C, the Coolant Heater, Oil Pan Heater, Battery Charger and Heater Pad, and Heated Breather Hose provide the ultimate solution. Unless you want to be stuck in the cold, contact your dealer to order the Tundra Package option. The Coolest Super Quiet Operation from a High Performance PackageToday’s applications require more than just reliable power, they demand quiet operation from packages that won’t overheat. Doosan Portable Power has taken on the challenge of Tier 4 emissions regulations, redesigning our mobile line-up with ground-breaking engineering. Utilizing a revolutionary enclosure that creates separate compartments for the powertrain and cooling system combined with the industry’s first mass production application of radial cooling fan technology, Doosan Portable Power now delivers the coolest and quietest mobile generators on the market without sacrificing performance or reliability – even at extreme temperatures. In addition, the new G70-G125 models feature a thermostatically controlled clutch driven cooling fan which provides quieter, more fuel efficient operation over a broad ambient temperature range.When it comes to innovation in mobile power generation, Doosan Portable Power leads the industry in providing features you can count on to meet the demands of critical applications under the harshest conditions. Our new generation of products powered by EPA Tier 4-interim emissions compliant engines are the quietest and most technologically advanced machines we’ve ever built, engineered to exceed the expectations of our customers.Operation and Control Made EasyCurb-side service access makes maintaining Doosan Portable Power’s generators easy and safe. Placing the battery, fuel and air filters, oil fill and fuel fill on the curb-side of the generator means that finding all of the routine service points is easier and does not expose the operator to oncoming traffic in urban applications. • Three position voltage selector switch is standard on all models up to the G325 and equipped with the industry’s only protection scheme that prevents operators from accidentally switching voltage during operation. • Larger, easier to read analog meters for at-a-glance monitoring of vital engine and generator parameters, plus on-board engine diagnostics and simple control and management of the engine emission controls ensure operators are always in command. • Redesigned connection panel provides safe and easy power wiring connections with bare end or terminated cables plus an optional camlock panel expands connection options. Also included is an array of twist-lock and GFCI receptacles for simple convenient connections. • Doosan Portable Power’s 600V option is now available for the new G70, G85, G125 and G150 through a unique feature known as Quad Voltage. Through an enhanced voltage selection design, the operator can select between 120/240V-1Ø, 208V-3Ø, 480V-3Ø or 600V-3Ø with the flip of a switch.Model G25WMI-2A-T4i G40WMI-2A-T4i G70WCU-3A-T4i** G85WCU-3A-T4i** G125WCU-3A-T4i** G150WCU-3A-T4i** G190WCU-3A-T4i G240WCU-3A-T4i G325WCU-3A-T4i G450WCU-2B-T2 G570WCU-2B-T2Prime Power RatingAmps kW kVA Amps kW kVA Amps kW kVA Amps kW kVA Amps kW kVA Amps kW kVA Amps kW kVA Amps kW kVA Amps kW kVA Amps kW kVA Amps kW kVA@ 480V-3Ø, 0.8PF, 60Hz 30 20 25 42 28 35 93 62 77 117 78 97 154 103 128 180 120 150 234 155 194 286 190 238 392 261 326 549 365 456 686 456 570@ 240V-3Ø, 0.8PF, 60Hz 60 20 25 84 28 35 185 62 77 233 78 97 309 103 128 361 120 150 467 155 194 573 190 238 784 261 326 1098 365 456 1371 456 570@ 208V-3Ø, 0.8PF, 60Hz 69 20 25 97 28 35 194 56 70 236 68 85 294 85 106 355 102 128 500 144 180 608 175 219 877 252 316 1259 363 454 1416 408 510@ 240V-1Ø, 1.0PF, 60Hz 4 Wire 28 20 20 39 28 28 86 62 62 108 78 78 142 103 103 167 120 120 215 155 155 264 190 190 363 261 261 504 363 363 567 408 408Zig-Zag 65 15.6 15.6 89 21 21 146 35 35 175 42 42 258 62 62 313 75 75 367 88 88 454 109 109 658 158 158@ 120V-1Ø, 1.0PF, 60Hz 4 Wire 56 20 20 78 28 28 171 62 62 216 78 78 285 103 103 283 102 102 400 144 144 486 175 175 700 252 252 1008 363 363 1133 408 408Zig-Zag 65x2 15.6 15.6 89x2 21 21 146x2 35 35 175x2 42 42 258x2 62 62 313×2 75 75 367×2 88 88 454×2 109 109 658×2 158 158@ 400V-3Ø, 0.8PF, 50Hz 76 50 63 93 62 77 131 87 109 195 108 135 238 132 165 260 144 180 354 196 245@ 600V-3Ø, 0.8PF, 60Hz** 77 61 76 100 83 104 123 103 128Voltage Configuration 3-Position Switch 3-Position Switch 3-Position Switch **(w/ Quad Voltage)3-Position Switch **(w/ Quad Voltage)3-Position Switch **(w/ Quad Voltage)3-Position Switch**(w/ Quad Voltage)3-Position Switch 3-Position Switch 3-Position Switch Link Board Link BoardFrequency Capability 60Hz Only 60Hz Only 50Hz/60Hz Switchable 50Hz/60Hz Switchable 50Hz/60Hz Switchable 50Hz/60Hz Switchable 50Hz/60Hz Switchable 50Hz/60Hz Switchable 50Hz/60Hz Switchable 60Hz Only 60Hz OnlyEngine Engine Make / Model Mitsubishi S4Q2-Y362 Mitsubishi S4S-Y362 Cummins QSB5-G7 Cummins QSB5-G8 Cummins QSB5-G 9 Cummins QSB7-G7 Cummins QSB7-G7 Cummins QSB7-G6 Cummins QSL9-G8 Cummins QSX15-G9 Cummins QSX15-G9Power Output @ 1800RPM - HP (kWm)31 (23) 42 (31.3) 100 (74.6) 126.7 (94.5) 154.7 (115.4) 232 (173) 232 (173) 282 (210) 393 (293) 544 (405) 680 (507)Emissions Tier Level Tier 4-interim Tier 4-interim Tier 4-interim Tier 4-interim Tier 4-interim Tier 4-interim Tier 4-interim Tier 4-interim Tier 4-interim Tier 2 Tier 2Fuel Tank Capacity - Gal (L) 36 (136) 47 (178) 189 (715) 189 (715) 189 (715) 368 (1394) 368 (1394) 368 (1394) 480 (1817) 574 (2173) 574 (2173)Runtime @ 100% Load - Hr 18.9 18.2 38.6 30.5 25.2 43 30 26 25 22.2 18.5Dimensions with Running GearLength - in (mm) 131 (3327) 144.4 (3668) 165.8 (4212) 165.8 (4212) 165.8 (4212) 216.7 (5503) 216.7 (5503) 216.7 (5503) 232.4 (6034) 260.9 (6627) 260.9 (6627)Width - in (mm) 59.5 (1511) 67 (1702) 71.7 (1820) 71.7 (1820) 71.7 (1820) 83.2 (2114) 83.2 (2114) 83.2 (2114) 83.0 (2109) 85.9 (2182) 85.9 (2182)Height - in (mm) 67 (1702) 68 (1727) 83.2 (2114) 83.2 (2114) 83.2 (2114) 102.9 (2615) 102.9 (2615) 102.9 (2615) 113.0 (2870) 119.8 (3043) 119.8 (3043)Weight (Ready to Run) - lb (kg) 2588 (1174) 3508 (1591) 7220 (3274) 7220 (3274) 7220 (3274) 10477 (4752) 10900 (4944) 10900 (4944) 13595 (6167) 18271 (8288) 18573 (8425)Sound Level @ 23 ft (7m) and 100% Load - dB(A)66 66 65 66 67 67 68 68 71 74 76G70-G325 are equipped with dual frequency capability allowing the user to choose either 50Hz or 60Hz frequency at the flip of a switch.
