Invertek - State of Charge Unit Brochure

SOC units can monitor the reading data of the battery pack and battery cells for the instantaneous State of Charge; Applicable for battery pack voltage up to 500VDC; Data values can be read out and programmed by Computer for remote operations; Accurate State of Charge reading with the measurement of shunt 500A / 50mV for SOCU-505A and SOCU-505B, SOCU-512A and SOCU-512B for 1200A / 50mV; 4setsof multi-function relays for the output signal of battery cell; Battery pack 18 LED Status Indicators on the panel for the indications of the battery cell voltage, battery pack voltage, 4 sets of relay outputs, communication status, state of charge, charge completion.
