Monocrystalline Modules WSP 285M6 Quantum Datsheet

100% 95% 90% 85% 80% 75%97%1 5 10 15 20 25About WINAICOAs a result of our passion for performance, we offer not only high performance photovoltaic modules, but also comprehen-sive support to the successful execution of photovoltaic projects.As a Taiwanese module manu-facturer with German and other subsidiary companies around the world, WINAICO is positioned amongst top brand manufactu-rers with a high-quality product from an automated production line. The parent company, Win Win Precision Technology Co., Ltd. has its origins in the semiconductor sector, which is subject to the same quality management demands as those applied in the solar industry. With leading-edge system tech-nology and process expertise originating from the semicon-ductor industry, WINAICO is setting qualitative benchmarks on the PV market.Thousands of installed systems are proving this every day.When you buy a WINAICO module, in the first year we gua-rantee a performance of at least 97% of rated performance. For the following 24 years, WINAICO guarantees a maxi-mum drop in performance of 0.7% of nominal performance per year. Through this promise, WINAICO guarantees the quality and performance of its own products and provides you with investment protection.Advantages of the WINAICO WSP-M6 QUANTUM modules + The WINAICO QUANTUM modules set a new technological standard and are without competition. Using innovative backside passivation and selective emitter technology, the QUANTUM module series combines highest efficiencies, increased performance at high temperatures and low light conditions along with the known longevity and quality of WINAICO + Linear performance guarantee over 25 years + 10-year product warranty + Anti-PID technology + Hot-Spot protection + Low initial degradation (LID)WINAICO WSP-M6 QUANTUMLinear guarantee for WINAICO module performanceGuarantee standard on the marketGuarantee advantage for WINAICO customersPerformance guarantee as %Years 80.2%25-year linear performance guaranteeID:0000028759Mechanical dataCell Monocrystalline 156 x 156 silicon cellsQuantity and wiring of cells 60 in seriesDimensions 1,665 x 999 x 40 mm (65.55 x 39.33 x 1.57 inches)Weight 19.7 kgGlass thickness 3.2 mm (0.13 inches)Connection type Tyco connection socket and connector (IP 67)Backsheet Black or whiteLimit values Operating temperature –40 to +90°CStorage temperature –40 to +90°CMaximum system voltage 1,000 VDCMaximum load 5,400 N/m2Maximum reverse current 15 AWSP series Front view Rear viewThe electrical data applies under standard operating conditions of the cells: 800 W/m2; 20 °C; AM 1,5; wind speed 1m/s. NOCT: 44.7°C (normal operating cell temperature). Subject to specification changes.Reduction in the module efficiency rating from 1,000 W/m2 to 200 W/m2: < 4%. The performance tolerance of this module is 0/+5 Wp. The electrical data ap-plies under standard test conditions (STC): Solar radiation 1,000 W/m2 with light spectrum AM 1,5 with a cell temperature of 25 °C. The measurement tolerance applied to all electrical values is -5/+5% (with the exception of Pmax (STC) and NOCT). Subject to specification changes.No guarantee is offered as to the accuracy of the information given. We reserve the right to make technical changes. 0912/agentur-bemberg.deWINAICO is a trademark of Win Win Precision Technology Co., Ltd. No. 96, 3F, Hsinho Road · Sinfong Township, Hsinchu County 304 · Taiwan R.O.C.Tel + 886 3 568 8699 · Fax + 886 3 568 8580 · www.wwpt.com.tw · www.winaico.com4mm (0.16 inches) cable, length 1000mm (39.37 inches) with TYCO connectorsElectrical data (STC) WSP-270M6 WSP-275M6 WSP-280M6 WSP-285M6Module type mono mono mono monoNominal performance Pmax 270.08 275.10 280.13 285.20 WpNo-load voltage UOC 38.06 38.25 38.45 38.64 VShort circuit current ISC 9.24 9.34 9.44 9.54 AVoltage at max. performance Umpp 30.59 30.98 31.37 31.76 VCurrent at max. performance Impp 8.83 8.88 8.93 8.98 AModule efficiency 16.24 16.54 16.84 17.15 %Temperature coefficient performancePmpp –0.4371 –0.4371 –0.4371 –0.4371 %/°CTemperature coefficient short circuit currentISC 0.0466 0.0466 0.0466 0.0466 %/°CTemperature coefficient no-load voltage UOC –0.3094 –0.3094 –0.3094 –0.3094 %/°CElectrical data (NOCT) WSP-270M6 WSP-275M6 WSP-280M6 WSP-285M6Nominal performance Pmax 199.41 203.12 206.84 210.58 WpNo-load voltage UOC 34.86 35.03 35.22 35.39 VShort circuit current ISC 7.42 7.50 7.58 7.66 AVoltage at max. performanceUmpp 27.89 28.25 28.60 28.96 %Current at max. performance Impp 7.15 7.19 7.23 7.27 AModule efficiency 11.99 12.21 12.44 12.66 %
