Osby PB2 - Solid Fuel Brochure (PDF 1702 KB)

For professional usersTelephone: +46 479 177 00 • info@osbyparca.se • www.osbyparca.seThe Osby PB 2 is a highly efficient hot water boiler specifically designed for firing wood pel-lets, briquettes or wood chips. Ease of operation together with reliability are paramount features of the design. Operation of the PB 2 requires only the minimal of manual intervention and a brief annual shut down for inspection and maintenance. The boiler’s automatic tube cleaning system ensures a high boiler efficiency is maintained without the need for frequent shut downs and manual cleaning. A hydraulically driven stepped grate automatically moves the fuel through the combustion chamber and discharges residual ash. Screw conveyors automatically remove ash and dust from the boiler, conveying it to a single collection skip. To increase flexibility, two types of control system are offered, one system for controlling the boiler functions via a simple display and a more comprehensive system for controlling an entire heating plant. It is possible to operate and monitor the system remotely.The Osby PB 2 is the result of many years experience in both boiler design and the handling and combustion of biomass. We have focused specifically on high efficiency, low running costs, low emissions, simple operation and reliability.Osby PB2350 to 3000 kWFully automatic biomass boilerOsbyParca • Osby PB 2949290888640 50 60 70 80 90 100 110 Boiler load %Boiler efficiencyBoiler efficiency %Mechanical Design Data25020015010040 50 60 70 80 90 100 110 Boiler load %Exhaust temperatureExhaust temperature °CPressure Operating maximum: 6 barTemperature Operating maximum 140°C Minimum water return 70°CInsulation: 70 mm mineral woolThe boiler is produced according to current stand-ards and directives in Europe or US. Boiler efficiency Exhaust temperatureOperational dataDry fuel firing such as pellets, briquettes or wood chips. Lowest floor temperatur 70°C.Functional DescriptionA reception hopper maintains a supply of fuel to the fuel feed conveyor. Level detectors in the reception hopper control the feeding of fuel from the storage silo to the boiler. A variable speed screw conveyor feeds fuel constantly onto the inclined grate where combustion takes place. The grate sits on a plate which forms an integral part of the boiler and both collects heat and cools the grate. Periodic automatic stroking of the grate by hydraulic actuators moves fuel through the combustion chamber and discharges ash into the ash screw conveyor. Fuel feed and air flow are automatically modulated to meet the heat demand from the boiler while maintaining the undergrate pressure and flue gas composition within normal operating limits. The boiler automatically controls between 25% and 100% of design thermal output. Monitoring systemWe offer two different control systems :The simplest system controls and monitors only the boiler functions presenting operating data on a numerical display format. The advanced system can be used to control the entire heating system including hot water distribution pumps and additional boilers. Information is displayed on a screen using clear graphical images. Both systems are capable of interrogation and operation remotely.Telefon: +46 (0)479-177 00 • info@osbyparca.se • www.osbyparca.seBoiler efficiency %Boiler load %Exhaust temperature °CBoiler load %OsbyParca • Osby PB 2Automatic tube cleaningThe boiler has an automatic cleaning system ensuring constantly clean flue gas tubes and a high boiler efficiency.Automatic ash handlingThe boiler is fitted with both an ash screw and dust screw. Operation of these screw conveyors is supervised by the control system and provides for the automatic discharge of ash and dust from the boiler.Air ControlCombustion air is drawn into the boiler by a variable speed exhaust gas fan. Throttles above and below the grate control primary and secondary air to the combustion chamber. The air flow to the combustion chamber automatically modulates to meet the thermal demand on the boiler. ServiceDesigned for ease of servicing• The Osby PB 2 is designed and built for operation with a minimal of servicing downtime.• Instrumentation, controls and operating components are easily accessible.• The grate is easily removed from the boiler for inspec-tion and maintenance by releasing a few conveniently located bolts. • The control system continuously monitors operation of the boiler and generates operating logs. In the event of equipment mal function or a parameter moving outside of normal limits the boiler is automatically controlled to a safe condition and an alarm generated.• The automatic tube cleaning system means that manual cleaning of the flue gas tubes is not necessary during the heating season.Telefon: +46 (0)479-177 00 • info@osbyparca.se • www.osbyparca.seCombustion chamberThe boiler is designed to give efficient combustion of the fuel to ensure minimal emissions.OsbyParca • Osby PB 210543210,50,20,10,0520 304050 100 %0 EffektuttagTryckfall kPa???Water resistenceDimensions* without water* The boiler is supplied with the ash screw unmounted ** = Minimum dimension (mm)Ash storage bin ChimneyPB2 boilerCyclone FanFuel storage*Concrete foundation with a hight of 600-700 mm is recommended. CONCRETE FOUNDATION*Technical dataBoiler type L L1 B B1* H H1 H2 H3 A1** A2 A3** A4PB2-350 3060 1150 1050 1730 2225 1825 400 300 500 400 500 800PB2-500 3530 1150 1050 1730 2225 1825 400 400 500 400 500 800PB2-750 3750 1150 1220 1900 2250 1850 400 400 500 750 500 1000PB2-1000 4012 1150 1390 2070 2445 2045 400 400 500 750 500 1000PB2-1250 4006 1150 1930 2610 2445 2045 400 400 500 1100 500 1250PB2-1500 4150 1150 1930 2610 3100 2600 500 400 500 1100 500 1250PB2-2000 5210 1150 1930 2610 3100 2600 500 400 500 1500 500 1400PB2-3000 5920 1150 2440 3120 4090 3590 500 400 500 1500 500 1400Boiler typePowerkWGas resist?p PaWeighttonne*Water volume m3Conn.DNFlue gas fan kWPB2-350 350 1200 5 1,5 80 3,0PB2-500 500 1200 6 2,1 100 4,0PB2-750 750 1200 9 3,5 125 5,5PB2-1000 1000 1200 11 4,5 150 7,5PB2-1250 1250 1200 13 6,0 150 7,5PB2-1500 1500 1500 14 7,0 150 11,0PB2-2000 2000 1500 18 8,0 150 11,0PB2-3000 3000 1500 26 13,5 200 18,5Technical dataPressure drop kPa% PowerOsby Parca Div. • Box 93 • SE- 283 22 OsbyTelefon: + 46 (0)479 - 177 00 • Telefax: + 46 (0)479 - 177 25info@osbyparca.se • www.osbyparca.seArt.nr. 4992-0101 Utgåva A Produktion: Joma GP 2009-04 Tecnical data may be subject to change without previous notice.
