SimpleChips - Model 16SCT000 - Transformer-Coupled FET/IGBT Gate Driver - Brochure

The 16SCT000 is an IGBT/MOSFET gate driver (15V nominal Vg) chip to control the conduction state of a high-side switch from the secondary of a small high voltage isolation transformer. The 16SCT000 will drive the gate of the HV switch above the emitter/source while the secondary winding of the transformer drives the complementary input signals. Upon cessation of the input drive signals, the 16SCT000 quickly clamps the gate to the emitter/source terminal to ensure fast turns off.
