Sun Bear - Fixed Tilt Ground Mount Racking System Brochure

Breaking New Ground The Sun Bear® ground mount system is not your traditional ground mount system. Just take a look – you’ll recognize that the Sun Bear design sets a new standard in the market, from its distinct truss structure to its efficient use of materials. With only four major components, three installation tools, and zero loose fasteners, the Sun Bear system drastically simplifies construction. Sun Bear Ground Mount Systempanelclaw.com4 COMPONENTS | 0 LOOSE FASTENERSComprehensive Project Delivery• Foundation Engineering• Geotechnical Services• Third-party Licensed Engineering Stamps• Racking Construction Drawings• Certified Installer ProgramFour Major Components and Zero Loose Fasteners 1 Sun Bear Foundation Helical, W6, and earth screw piles. Includes built-in keyhole design for easy attachment to Sun Bear Struts. 2 Sun Bear Strut Galvanized steel struts with integrated turnbuckles. Locks to foundation using built-in fastener and jam nut design. 3 Sun Bear Claw Used to secure modules to the Sun Bear Frame without any loose fasteners. 4 Sun Bear Frame Pre-assembled and pre-squared frame designed with nested rafters to optimize shipping capacity.Sun Bear Ground Mount SystemSpecificationsGrade of Terrain Default slope up to 10°Module Tilt Angle 20°, 25°, 30°Table Options Landscape with two sizes: Twelve 72-cell modules (4x3) Eight 72-cell modules (4x2)Foundation Location Tolerance 12” diameter and 6” height Ground Clearance Minimum of 36” lower drip-edge height Wind and Snow Load Designed to ASCE and IBC requirements for snow loads greater than 50 PSF and wind speeds above 140 MPHMaterial Composition Sun Bear Claw: Aluminum 6061-T6 and 304 SS Sun Bear Frame and Sun Bear Struts: Galvanized Steel and Zinc-Aluminum Alloy Sun Bear Foundations: Hot-dipped galvanized steel (W6)Thermal Growth Capacity Inherently designed to accommodate thermal growth and contraction in all environmentsWire Management Stainless steel hooks in multiple sizes for easy East-West wire managementIntegrated Grounding ETL Classified to UL 27031 2 34For Product and Sales Information: 978.688.4900 or sales@panelclaw.comPrinted on recycled paperwww.panelclaw.com© 2014 PanelClaw, Inc.
