Lifepo4 Sandi - Model SPVLI-100kWh -100kwh Lithium Battery 200ah Battery Pack for Solar Energy System
This product is composed of high quality lithium iron phosphate core (series-parallel connection) and advanced BMS management system. It adopts master-slave mode, which is convenient for monitoring and controlling the input and output system. The charging and discharging are independent, it can control the charging current of the AC charger and solar controller according to the battery temperature, voltage and SOC to better protect the battery cells from overcharging, overheating and discharging. It has high reliability and long life, products developed for applications such as solar energy storage, industrial and commercial energy storage, household energy storage, charging piles, data room and other applications.
Most popular related searches
lithium iron phosphate
lithium battery
solar energy
commercial energy storage
domestic energy storage
energy storage
solar charge control
battery management system
solar energy storage
solar charge controller
- Model No.: SPVLI-100kWh
- Brand Name: SANDI
- Country of Origin: China
- Unit Price: US $ 33800 / pc
- Minimum Order: 1 pc
- All-in-one design, high integration and space saving installation;
- Using high-performance lithium iron phosphate cells, laser welding, good cell consistency, designed service life of more than 10 years;
- Charging and discharging are controlled separately, which is convenient and reliable to control charging and discharging. The discharge port will not be disconnected when over-charging, and the charging port will not be disconnected when over-discharging, the system has good stability;
- Master-slave mode, passive equalization, can manage the equalization resistance, can set the equalization start voltage difference, and monitor the equalization resistance temperature, more intelligent and safe, and reduce the impact of barrel effect on system energy storage;
- BMS adopts NXP(USA) automotive-grade high-performance chips, with strong anti-interference, good reliability and wide temperature range;
- CAN2.0 communication interface, has the advantages of strong real-time performance, long transmission distance, strong anti-electromagnetic interference ability;
- System parameters can be set through the host computer, such as fan start/stop temperature, charger maximum current setting, charge and discharge current correction, SOC correction, with insulation leakage detection function to prevent oil leakage and short circuit of the cell;
- Integrate Solar charge controller or AC charger optional, BMS communication control, more safe and reliable;
- Cell temperature management, can be automatically controlled with the air conditioner heater according to the cell condition to make the cell works at the most suitable temperature, and can be linked with the fire protection system as needed
- Sma size and ight weight, Maintenance-free;
- Environmenta protection and poution-free materias, no heavy;
- Accuratey estimate the state of charge of the battery pack, that is, the remaining power of the battery, to ensure that the power of the battery pack is maintained within a reasonabe range;
- Buit-in BMS management system with comprehensive protection and monitoring contro functions;
- 5" CD screen dispay, easy to operate, can check the temperature, votage, working status, discharge current, dynamic and static SOC agorithm of a singe ce, oca dispay of aarm info, aarm eve distinction, accurate positioning of abnorma ces;
- Main contro MCU can be centray controed and manage periphera settings (AC charging modue, inverter modue, soar charging modue) to adjust the charging current and votage of periphera devices according to the battery charging curve, making the system more reiabe;
- BMS battery management system, with SOC automatic caibration and high current passive baance function, combined with perfect operation contro and management strategy, to achieve accurate and efficient management;
- EMS energy management system, BMS with soar controer/AC charger, inverter centray manages charge and discharge, effectivey contros the charge and discharge current within the ce usage conditions, protects the ce and extend its service ife;
