Model EKHE401VSN241MQ25Z - 105? Snap-in Type Aluminum Electrolytic Capacitors KHE Series

World’s top capacitance. BEST suited for high output power supplies used in servers for data centers.

Most popular related searches

Part Number: EKHE401VSN241MQ25Z

Status: In Production

Series: KHE

Polarity: Polar

Category Temperature Range: -40~105 ?

Rated Voltage: 400 Vdc

Capacitance: 240 µF

Capacitance Tolerance: -20~20%(M) / 20?, 120Hz

Dimensions ? D: 25.4mm

Dimensions L: 25mm

Rated Ripple Current: 1170mArms / 105? / 120Hz

Leakage Current: 929 μA max / 20?, after 5 minutes

Dissipation Factor (tanδ): 0.2 max / 20?, 120Hz

Endurance Temperature/Time/Overload: 105? / 2000hrs / DC+Ripple

Shelf Life Temperature/Time: 105? / 1000hrs

Terminal Coating: Sn

Reference Weight: 20g

Minimum Order Quantity: 200 pcs

RoHS Compliant: Compliant
