FuturEnergy - Model AirForce 1 - 1kW Horizontal Axis Upwind Turbine System
FromFuturEnergy Ltd
With more than 6,000 AirForceTM 1 wind turbines now in service world-wide, the highly robust and dependable turbine demonstrates enviable capability in energy generation in an extensive range of applications, such as: Battery charging. Water and air heating and cooling. Grid-tied/off-grid mains installations. Island networks and smart grids. Wind & solar hybrid solutions. Telecoms ‘hop’ stations. All turbines are designed & manufactured in the United Kingdom within a continuous product improvement policy. The AirForceTM 1 turbine is supplied in kit form and tower-top ready for simple installation on a standard 48.5mm scaffolding tube pole.
Most popular related searches
hybrid wind and solar
permanent magnet generator
heating and cooling
solar hybrid
wind and solar
smart grid
wind turbine
horizontal axis turbine
hybrid solar
solar wind
- FUTURENERGY high quality Permanent Magnet Generator
- 12 months’ warranty (extended warranty available upon registration)
- AirForceTM Control Monitoring and Automatic Stop System
- Remote-mounted manual stop-switch supplied as standard
- Suitable for wind/solar hybrid installations
- Full installation kits available
- Tough glass reinforced nylon turbine blades
- All bearings sealed for life
- 20 year installed design life
- 60 Amp rated slip-ring to prevent cable twist
- Rugged, simple and robust design
- Corrosion resistant materials employed throughout
- Restriction of Hazardous Substances (ROHS) compliant
- Nominal power output: 24V & 48V: 1000W
- Start-up wind speed: 3.5m/s
- Rated wind speed: 12.5m/s
- Survival wind speed: 52m/s
- Total tower-top weight: 19kg
- Number of blades: 3
- Rotor diameter: 1.8m
- Rotor speed (RPM): 200 to 800
- Number of blades: 3
- Generator type: 3-Phase AC
- Turbine mounting: 50mm tube to accept 48.5mm standard scaffold tube
- Noise: LAeq 35dB @ 5m/s wind speed measured behind rotor SPACE1LAeq 54dB @ 7m/s wind speed measured behind rotor
