Alliot Netvox - 250A Clamp-on three-phase Current Meter
The Netvox 250A 3 phase current meter with split core is used to detect three phase electrical input current. The device is compatible with the LoRaWAN® protocol, and integrates a chip module that conforms to the LoRaWAN® wireless protocol, and joins the gateway to display the collected data in the gateway. The device is powered by a battery and receives AC current through a current transformer. This device adopts open-loop current transformer, which can be easily connected to the device to be tested. The A phase line, the B phase line and the C phase line of the three-phase electric power are respectively connected to the corresponding current transformers.
- LoRaWAN® Class A compatible
- Requires 2 x ER14505 AA Lithium batteries
- Frequency Hopping Spread Spectrum (FHSS)
- Improved interference immunity
- Improved power management for longer battery life
- Encrypt-RF Security (Diffie-Hellman Key Exchange + AES-128 CBC for sensor data messages)
- Battery Life of up to 5 years (determined by sensor reporting frequency and other variables)
- Over-the-air updates (future)
We can supply third-party online wireless sensor monitoring and notification system to view data and set alerts via SMS text and email.
Ask us about our zero-touch provisioning service, this sensor can be supplied pre-configured and ready to go.
Electric:
- Input Power : 2 x 3.6V ER14505 AA lithium batteries (3.6V2400mah/section)
- Sleeping Current : 25uA
- Wake Up Current : 7mA
- Receiving Current (Max) : 11mA/3.3V
- Transmitting Current (Max) : 127mA/3.3V
- Battery Voltage Measurement Accuracy : ±0.1V
- Current Measurement Accuracy : <+-1%
- Current Measurement Accuracy Range : 1A to 250A (depending on the current transformer configuration)
Frequency:
- TX Power : 19dBm±1dBm
- Rx Sensitivity : -136dBm (LoRa, Spreading Factor=12, Bit Rate=293bps)
- -121dBm (FSK, Frequency deviation=5kHz, Bit Rate=1.2kbps)
- Antenna Type : Built-in Antenna
- Communication Range : Up to 10 km (line-of-sight, actual transmission distance depends on the environment)
- Data Transfer Rate : 0.3kbps~50kbps
- Spread Technique : LoRa/FSK
- Available Frequency : EU868 (others are available on request)
Physical:
- Dimensions : Main Part: 112mm x 65mm x 32mm
- Weight : 141g
- Environment Temperature Range : -20%deg;C ~ 55°C
- Environment Humidity Range : <90% RH (No Condensation)
- Storage Temperature : -40°C ~ 85°C
