Sunport - Model S-Flex 6 II -360-380W MWT Mono PERC Flexible PV Module

Light,Thin design
5.7kg weight, 2.5mm thickness, match various requirements for low-load projects

High Efficiency And Reliability
Busbar-free design increases cell conversion efficiency,more power output can be achieved at low irradiance conditions

Customizable
Customized design for different scenarios

Convenient Installation
Easy installation and convenient transportation with lower cost

Lead Free
Eco-friendly PV design achieves lead-free MWT module without soldering materials

Nominal Module Operating Temperature: 43±2^oc
Temperature coefficient of Pmax: -0.36%/^oc
Temperature coefficient of Voc: -0.28%/^oc
Temperature coefficient of Isc: 0.06%/^oc

Installation Module Dimension (L×W×H): 1840mmx1040mmx2.5mm
Weight: 5.7kg
Back material: Back Sheet(black)
Cell (quantity / material / type / dimensions): 126(21x6) / Mono / Half-cell
Encapsulant: POE
Frame: None
Junction box(protection degree): IP68
Cable (length/cross-section area): Customizable / 4mm2
Bending radius: 0.3m

Max. system voltage: DC1500V(IEC)
Max. series fuse rating: 18A
Operating temperature range: -40^oc~+85^oc
Connector: MC4 Compatible
