Aboveground Fuel Tank

Technical features:

• made of top quality carbon EN10025 S235JR steel sheet, painted externally
• Quick-fit filling tap 3” in brass, lockable;
• Limiting valve 90%;
• Brass air vent 1”1/2 with flame arrestor net;
• Level indicator with floater visible from the outside;
• Manhole diam. 420 mm fitted with gaskets and bolts;
• Lifting eyebolts for empty tank;
• Drain coupling on lower front end of the basin, for periodical maintenance, fitted with safety tap;
• Grounding bolt;
• Suction coupling 1” in higher position than the bottom of the tank, allowing dirt to settle on the bottom, including no return valve 1”;
• Sphere tap 1”;
• Galvanised steel pipe 1” connecting tank and dispenser with flexible pipe 1” R1


Containment basin

With a self-supporting frame fixed to the feet of the tank. Arranged with fittings for fixing of the roof. 3/4” dia. drain plug.
Designed to contain 50% of the total volume of the tank (100% capacity on request), made of top quality carbon EN10025 S235JR steel sheet, fully painted.

Protection Roof

Made of galvanized corrugated sheet steel and mounted on a sturdy, self-supporting, fully galvanised frame.

Type approved aboveground fuel tank, homologated for the supply of diesel fuel for generator sets or heating oil.
With homologation no.7767/4113 subsection 269 and subsequent revisions, issued by Italian Ministry of the Interior with reference to Italian Ministerial Decree dated 19.03.90.

Ministerial Decree dated 13.07.11

Custom Agency prescription 33/D dated 15/09/2006

Tank

Technical features:

• made of top quality carbon EN10025 S235JR steel sheet, painted externally
• Quick-fit filling tap 3” in brass, lockable;
• Limiting valve 90%;
• Brass air vent 1”1/2 with flame arrestor net;
• Level indicator with floater visible from the outside;
• Manhole diam. 420 mm fitted with gaskets and bolts;
• Lifting eyebolts for empty tank;
• Drain coupling on lower front end of the basin, for periodical maintenance, fitted with safety tap;
• Grounding bolt;
• Suction coupling 1” in higher position than the bottom of the tank, allowing dirt to settle on the bottom, including no return valve 1”;
• Sphere tap 1”;
• Galvanised steel pipe 1” connecting tank and dispenser with flexible pipe 1” R1


Containment basin

With a self-supporting frame fixed to the feet of the tank. Arranged with fittings for fixing of the roof. 3/4” dia. drain plug.
Designed to contain 50% of the total volume of the tank (100% capacity on request), made of top quality carbon EN10025 S235JR steel sheet, fully painted.

Protection Roof

Made of galvanized corrugated sheet steel and mounted on a sturdy, self-supporting, fully galvanised frame.
