WelinkModel HSI 5500 -All-in-One Solar Charge Hybrid Inverter

SHARE

Performance characteristics:  Load friendly: Stable sine wave AC output via SPWM modulation. Supports a wide range of battery technology: GEL, AGM, Flooded, LFP, and program. Dual LFP battery activation method: PV&mains. Uninterrupted power supply: simultaneous connection to utility grid/generator and PV. Intelligent programming: the priority of the output from different energy sources can be set. High energy efficiency: up to 99.9% MPPT capture efficiency. Instant viewing of operation: the LCD panel displays data and settings ,while you can also be viewed using the app and webpage. Power saving: power saving mode automatically reduces power consumption at zero-load. Efficient heat dissipation: via intelligent adjustable speed fans. Multiple safety protection functions: short circuit protection, overload protection, reverse polarity protection, and so on under-voltage and over-voltage protection and reverse polarity protection.

Most popular related searches
  • Model Name: HSI 5500
  • Rated Output Power: 5500VA
  • Rated Voltage: 48V
  • PV: 500V
  • AC: 220/230V
  • Battery Type: Sealed?FLood?GEL?LFP?Ternary
  • Energy Efficiency: Up to 99.9% MPPT capture efficiency
  • Dimensions: 426mm*322mm*126mm
  • Weight(KG): 10.5
