Kingfeels - Model KF-CR-17 - Aluminum Ground Mounting Structure for Solar PV Systems
As Alumimum Solar PV Mounting Systems uses anodized aluminum alloy structure, making the whole system light-weight, durable, recyclable and highly stron g. Flexiblity in height and angle adjustment makes the system applicable for different types of landforms.
- Item NO.: KF-CR-17
- Payment: T/T, L/C
- Product Origin: China
- Lead Time: 7 days
- Material: Aluminium, Steel
- Color: Silver, Black
The main material of the system is high-strength aluminum, and bolts are all stainless-steel, so the anti-corrosion and self-recovery effect is very good, especially suit for island countries, such as Japan, Singapore ,Philippines.
The aluminum ground mount structure can match different base, for example ground screw, pile or concrete foundation. It also can used on flat ground or little slop ground. The array can be placed 2*n vertically, 3*n, 4*n horizontally, or larger arrays can also be done, but the difficulty of construction also needs to be considered when selecting the array. If the height of the upper end of the module is particularly high, the construction on site will be very difficult. The selection of span depends on the parameters of wind load and snow load of the project site. Through calculation, we can get the number of foundations. Of course, in the process of design, we also need to consider the situation of land as much as possible. If the customer can provide soil report and foundation test report, Kingfeels aluminum solar engineer team can provide a more accurate design.
- Install Site: Open field area
- Max Wind Speed: ≤60m/s
- Snow Load: ≤1.4KN/M2
- Tilt Angle: 0-45 degree
- Applicable Module: Framed or frameless
- Module Orientation: Landscape, portrait
- Standards: AS/NZS 1170, ASCE 7-10, JIS2017
- Material: AL6005-T5, SUS304
- Anti-corrosive: Anodized
- Color: Silver, Black
- Warranty: 12 years
- Top quality with competitive price---one of the biggest aluminum solar mounting manufacturer with integrated production in Xiamen.
- To provide you with the most cost-effective solar racking solution.
- Full anodize for all components---offering 12 year warranty and 25 year life time.
- Excellent design ability---over 20 structure engineers, the chief engineer has 10 years` experience of structure engineering for aluminum solar mounting systems.
- Components are highly pre-assembled at the factory, saving you a lot of time and cost.
