Anaerobic Digester Vortex Module
TERIX-Envirogaz’s process uses a mixing system that creates a movement optimized for anaerobic digestion, thus preventing the formation of crusts and the accumulation of deposits. The system, installed in each digester, creates a vortex that keeps solids from SOFs in an homogeneous suspension and maintains a constant temperature, which optimizes process efficiency and performance.
-
Most popular related searches
Benefits
- Jets create a vortex that optimizes the digester’s productivity
- Mixes SOFs at various levels inside the digester
- No moving components inside the digester, thus preventing maintenance inside the unit
- Allows for the mixing of various digesters through one central pumping system
- Pumping assembly easy to access and protected from adverse weather
- Platform or in-container plant assembly for ease of installation
Characteristcs
- Ensures an homogeneous mix in all types of digesters, regardless of the level of SOFs inside, thus providing highly flexible operations
- All mechanical components are located outside the digesters, thus ensuring ease of maintenance and operator security
- Injection nozzles are located along the height of the digester, thus creating a vortex from top to bottom
- Feeders are pre-assembled on a platform or in a container, thus reducing on-site assembly time and ensuring product quality
- Uses six to ten nozzles, based on digester size, for increased performance
- Works intermittently, which generates considerable energy savings
Specification
- Volume Capacity per Digester:Between 1000 m³ and 5000 m³
- Pump Type: Centrifugal shredding
- Power Consumption: 26 kW for a 2000 m³ digester
- Pump Capacity: 5.67 m³/h for a 2000 m³ digester
- Nozzles Used: Between 6 and 10, based on needs
- Nozzle: Hi-chrome cast iron with epoxy lining
