Model AZ6A8 - Analog Input Brush Servo Amplifiers

The AZ Series PWM servo drives are designed to drive brush-type DC motors and voice coils at high switching frequency. To increase system reliability and to reduce cabling costs, the drive is designed for direct integration into your PCB. The AZ6A8 is fully protected against over-voltage, over-current, over-heating and short-circuits. A single digital output indicates operating status. The drive interfaces with digital controllers that have analog +/-10V output. This servo drive requires only a single unregulated isolated DC power supply, and is fully RoHS (Reduction of Hazardous Substances) compliant. Z-Drives are a culmination of advances in manufacturing technology. By utilizing dual sided PCB boards, high efficiency power devices and creative design we are able to make the Z-Drives possible.
