YTL - Model D511001 - Anti-Tampering Stepper Counter Three Phase Seven Module Energy Meter
This is a three phase seven module anti-tampering energy meter, which only have kWh measurement. It is widely used in Sub-metering system.
Most popular related searches
energy meters
energy meter
energy metering
three-phase energy meter
three-phase electricity meter
smart energy meter
smart electricity meter
electricity meter
- Voltage: 3*220/380V
- Current: 3*5(100) A
- Accuracy class: 1.0
- Standard: IEC62052-11, IEC62053-21
- Frequency: 50Hz
- Impulse constant: 8000imp/kWh
- Display: Counter 6+1
- Temperature range: -40～80℃
- Relative Humidity: ≤95%
- A Power Indication of Phase A
- B Power Indication of Phase B
- C Power Indication of Phase C
- D Impulse Output
Material
- Case Grey flame resistant ABS
- Terminal cover Grey flame resistant ABS
- Base Bottom Grey flame resistant ABS
Take one standard 35mm guide rail (the length is intercepted according to the actual situation) and fix it in the position
where the metering device is to be installed.
Push the clasp at the bottom of the metering device downward, and after it is stuck on the guide rail, the clasp of the metering device is pushed upward again, so that the metering device is completely stuck on the guide.
