Eaton - Model ATC-900 -Automatic Transfer Switch Controller
The ATC-900 brings reliability, intelligence, and programming capabilities to automatic transfer switch equipment. Easy-to-use, adaptable and flexible, the ATC-900 also allows for field configurability and expandability.
Most popular related searches
- USB functionality for set points, historical data and more
- Historical log of 450 time-stamped events
- Up to 20 configurable inputs and outputs
- Simple arrow keys for quick screen navigation
- No codes or abbreviations
- Screens grouped for ease of viewing and edits
- Password protection
- Unmatched degree of programmed flexibility
- Reduces installation and start-up costs
- Integration in building management systems
- 0 to 600V system voltage that’s field programmable
- Master and slave controller functionality for three source applications
- Selective, automatic load shedding
- USB port for uploading and downloading event data
- Eaton’s PowerXpert Gateway Module provides Modbus TCP/IP, SNMP, or BacNet protocol, for up to 32 transfer switches or other Eaton communicating devices.
- I/O module provides additional user configurable inputs and outputs. One I/O module adds four additional inputs and outputs and up to four modules can be daisy chained to the ATC-900 controller.
- DCT Metering Module provides a DC power input and load metering for diagnostic and troubleshooting features such as selective load shedding and event capture
- Eaton’s HMi transfer switch remotes annunciator and controller provides remote monitoring for up to eight transfer switches.
