Zwayn - Model ES-5120 - Battery Module for Solar Energy Storage

• Model: ES-5120
• Battery Type: LiFePO4 Battery Module
• Battery Voltage: 51.2V
• Battery Capacity: 100Ah
• Communication: RS485/ RS232/ CAN
• Application: Solar Household Commercial / Industrial / Energy Storage System ESS

ZWAYN ENERGY lifepo4 battery is specially and independently developed by ZWAYN solar battery engineering team within 2 years. The design can have included 15S-48VDC( for all hybrid off grid 48VDC inverters) and 16S-51.2VDC ( for all hybrid smart on-off grid 48vdc inverters), capacity with 5kwh, 7.5kwh, 10kwh range, max supporting 14pcs to reach 140kwh 48Vdc lifepo4 battery system.

ZWAYN ENERGY related smart BMS has functions of overcharge detection; over discharge detection; over current detection; short detection; Temperature detection; but also has functions of balance ; communicate ; alarm ; total capacity; storage history,etc.

• Model: ESS-5120
• Battery Type: LiFePO4
• Energy: 5120Wh
• Rated Capacity: 100Ah
• Rated Voltage: 51.2V
• Battery cell: 3.2V 100Ah Prismatic Battery Cell
• Configuration (*S*P): 16S1P (51.2v 100Ah)
• Discharge Cut-off  Protect Voltage: 40V
• Charge Cut-off Protect Voltage: 58.4V
• Max. Charge Current: 100A
• Max. Discharge Current: 100A
• Communication Port: CAN, RS485, RS232
• Compatible Inverter Brand: SMA, Growatt, Solax, Solis,DEYE,Sungrow, Sofar, Voltronic, Sorotec, Studer, etc.
• Module Parallel ability: 1S1P~1S15P(Low Voltage System);
• Cycle life: 80% DOD 5000 times
• L*W*H (mm): 442*430*177mm/module
• Net Weight (KG): 45KG
• Cooling: Natural cooling
• Environment: Indoor
• Discharge Temperature (?): -10?~+60?
• Charge Temperature (?): 0?~+45?
• Storage Conditions: –20°C to 30°C (–4°F to 86°F)Up to 95% RH, non-condensingState of Energy (SoE): 25% initial
• Maximum Elevation: 3000 m (9843 ft)
