Biogas Genset
Gas Components: Biogas is a mixture gas, main composition is methane(CH4) and carbon dioxide. Methane covers 45%-70%, carbon dioxide covers 30%-40% and also a bit of other gas like hydrogen, carbon monoxide, Hydrothion sulfide oxygen, nitrogen, etc. Because there are abundant of methane, the biogas can be used as a kind of fuel. Biogas is a kind of product that organization is resolved by bacterium under the anaerobic condition. Garbage in the city, sludge in the sewage treatment plants, excrement plants, excrement and straws all can be used to generate biogas.
Most popular related searches
air-fuel ratio controller
high energy igniter
biogas
gas generator set
gas main
biogas generator set
clean energy
biogas production
carbonization
methane biogas
Requirements for biogas:
- 40% The ration of Ch4 in biogas ≥40%;
- Pressure:3-20kpa, Pressure changing rate ≤1kpa/min;
- H2S≤200mg/m3;
- Moisture in biogas ≤40g/m3;
- Impurity Particle size ≤5μm, impurity content ≤30mg/Nm3;
- Biogas humidity ≤ 40℃;
- NH3≤20mg/m3.
EXON gas Genset feather:
- use CUMMINS NGV engine, advanced structural innovation (water/oil cooled turbocharger technology, low friction technology, corrosion-resistant valve technology, compression ratio optimization, electrical cabinet integrated, institutional and more compact, lower cost, easy maintenance);
- advanced control technology (with EXON control system, to achieve low-pressure combustion, lean burn, high-energy ignition, advanced closed-loop control, adaptive transient, fully functional start, EOBD);
- low exhaust temperature, long life;
- free switching function of Genset from 50HZ↔60HZ, is possessed of stronger applicability and generality. Reduce the cost;
- can use a potentiometer to adjust the target speed;
- our air-fuel ratio control system developed for real-time feedback via the lights. From the light color, brightness, on-off get real-time air-fuel ratio operating range. To provide a good reference for the running state of the engine;
- a wide range of the gas;
- high economic;
- flexible maintenance;
- high emission;
- all-electronic intelligent control, high automation level.
