Sitong - Model DZH - Biomass Moving Grate Steam Boiler

• Steam capacity 0.5t/h-4t/h
• Steam Pressure 0.7Mpa-1.6Mpa
• Fuel Biomass Pellet, Wood Chips, Bamboo Chips, Straw, Rice Hull, Peanut Shell, Bagasse, Mustard Stalk, Cotton Stalk, Cotton Seeds, Coconut Shell, Corncob, Waste Cloth, Etc.
• Application Textile Industry, Food Industry, Sugar Industry, Paper Industry, Chemical Industry, Garment Industry, Waste Processing Industry, etc.
• Certification ISO,CE,CCC,ASTM

Different from coal-fired boiler structures, the main features of biomass fuel boiler are as follows :

1. through the design of the secondary air in the chamber, disturb the flue gas power condition, timely supplement oxygen which is combustion and volatile. Improving       the thermal efficiency and reduce emissions.
2. The reasonable design can ensure the protection of the arch and the back of the grate, and avoid periodic micro-explosion in chamber. For the contained water waste, increase the length of preheating section, provide effective heating source to heat or directly put into hot flue gas high temperature segment.
3. According to various requirements of different biomass fuels, our company can individually design and provide best value products for users.

Steam boiler is widely used in Medicine, chemical, light industry, textile, building material, cultivation, food and beverage, plastic foam, printing washing, rubber processing, paper making, wood processing, hotel and garment manufacturing and tanning , etc.
Hot water boiler is widely used in hospital, school, hotel, neighborhoods and bath center, etc. Supply heating and hot water for user.

1. In accordance with the fuel character, adopt artificial feeding and mechanical feeding;
2. By adjusting the secondary speed air volume, control the speed of combustion ignition;
3. Long wood log (length is no more than 2m) can be burned without crushed
4. Stable running, convenient to adjust, enough output.
5. Compact structure, compared with the same type boiler, it has smaller size, which save the investment of the boiler room.
6. Do not require uniform feeding.
