BLITZDUCTORconnect - Modular - Universal Lightning Current / Surge Arrester
From IT-Systems - Yellow/Line- Surge Protection for IT Systems- Pluggable DIN Rail Mounted SPDs
The combined lightning current and surge arresters of the BLITZDUCTORconnect series are designed for universal use and system protection in industrial environments, at information technology signal interfaces, and in the field of automation or measuring and control technology:
-
Most popular related searches
Products Details
- Universal lightning current and surge arrester
- For protecting measuring and control circuits, bus and telecommunication systems
- High total discharge capacity of 3 kA (10/350 µs), 10 kA (8/20 µs)
- Max. impulse current carrying capability (8/20 µs) Imax up to 20 kA
- Arrester consisting of a module and base part
- Fast and simple cable connection thanks to push-in connection terminals
- All protection components integrated in the module
- secR release buttons on both sides for safe module replacement
- High system availability thanks to fail-safe performance Function-optimised design with a width of 6 mm
- LifeCheck and visual status indication integrated in the module
- Simple remote signalling of the status with the help of an optional remote signalling unit
- Tool-free signal disconnection for maintenance purposes
- Vibration and shock-tested for safe operation
