ETTER Engineering - Model FMA-3 Series -Boilers
ETTER Engineering has developed a line of Enhanced Operator Interfaces, Series FMA-3X, designed to work exclusively with the SIEMENS LMV- 3 Series of Linkage-less Burner Management Systems. The Operator Interface is a color touch-screen which replaces the single line AZL for Daily Operations, and provides graphical display of operating status, parameters, faults and alarms.
Most popular related searches
burner management system
burner management
burner
burner fuel
burner system
ignition system
burner operation
The FMA-3 Series provides a user-friendly interface to the LMV-3, with details such as:
- 4” Color TFT Touch Screen
- 7” Color TFT Touch Screen
- Remote communications to BMS and other devices
- Graphical display of the process
- Alarm logging with history
- Optional 16 point digital Input Annunciator for:
- Permissive & Running Interlocks
- On-Screen display of up to five limits
- First Outage Annunciation with time and date logging of each independent fault
- Optional enclosure version for existing field retrofits
Parameters Available Through the FMA Enhanced Interfaces Include:
- Burner Phase
- Fuel Actuator Position
- Fuel Selection
- Flame Signal
- Safety Loop Data
- Low Gas Pressure Switch
- High Gas Pressure Switch
- Air Pressure Switch
- Controller On/Off State
- Valve Proving System Status
- Ignition On/Off
- Fan On/Off
- Running Mode
- Start Counter
- Last Error Code
- Last Error Diagnostic Class
- Last Error Class
- Last Error Phase
- Error History, up to last 24 Errors
- Last Error Time & Date
