AEC - Cable Car 24-110V Charger
Thyristor control with full bridge rectifier. Rated voltage and current limit at output side. Built in the features of low ripple, low noise, alarm indications, comprehensive protection. Stable control circuit to provide a stable DC output power. Using nontoxic electric cable for wiring.
Most popular related searches
load current
battery charger
voltage regulation
voltage regulating
voltage regulator
power factor
switchgear
voltage limiter
power cable
voltage rectifier
- AC input
- Voltage：3Φ440V±10%
- Frequency：50 or 60Hz±5%
- Power factor：0.8(at full load)
- Output capacity：15kW(at 110V) 12kW(at 29V)
- Output voltage Float voltage：112.5V(adjustable) 29.6V(adjustable)
- Equalize voltage：118V(adjustable) 31V(adjustable)
- Voltage regulation： ±5%(at rating load)
- Efficiency：>80%(at rated load)
- Current limit：adjustable from 50% to 130%
- Ripple：<5%RMS(at full load)
- Telephone exchanges
- Satellite base-station
- Microwave links
- Rural telecommunications
- Railway switching controls
- Switchgear
