ADDI-DATA - Model APCIe-1016 - DAQ PCI-Express Card with Digital Inputs
The APCIe-1016 is a PCI-Express card that features 16 digital inputs operating at 24 V, designed for various industrial applications. It's compatible with the PCI version APCI-1016, making it an adaptable solution for those transitioning systems. The card is particularly effective for industrial I/O control, signal switching, and interfacing with electromechanical relays. It's also suitable for use in automated test setups and for monitoring the ON/OFF status of motors and lights. The card provides an interface for machinery connectivity, enhancing operational efficiency. This DAQ card supports a range of software environments and comes with standard drivers for Windows and Linux. It's equipped with safety features tailored for industrial usage and demands. Users can expand its capabilities through necessary accessories and compatible extensions available from ADDI-DATA. Comprehensive drivers, manuals, and programming samples are available for download to facilitate integration and application, making it an optimal choice for industrial digital input solutions.
The PCI-Express card with 16 digital inputs APCIe-1016 has 16 digital inputs, 24 V. The board is connector- and software-compatible to the PCI version APCI-1016. It is especially suited for industrial I/O control, signal switching, as interface to electromechanical relays, for automated test devices, for ON/OFF monitoring of motors, lights etc. and as interface to machines.
Features
- Connector and software compatible to the digital I/O board APCI-1016 for the PCI bus
Inputs:
- 16 optically isolated digital inputs, 24 V
- Reverse voltage protection
- All inputs are fi ltered
Safety features
- Optical isolation 1000 V
- Creeping distance IEC 61010-1
- Protection against fast transients (burst), overvoltage, electrostatic discharge and high-frequency EMI
Applications
- Industrial I/O control
- PLC coupling
- Signal switching
- Interface to electromechanical relays
- ON/OFF monitoring of motors, lights…
- Interface to machines
Software
Standard drivers and samples for:
- Linux
- Windows (32/64)
- Real-time with Linux (i.e Xenomai) and Windows (i.e RTX) on request
On request:
Further operating systems, compilers and samples. Driver download: www.addi-data.com/downloads
